Yokogawa AAV542-S00 Analog Output Module
The AAV542-S00 is an Analog Output Module designed for generating -l0 to+10 V DC signals across 16 non-isolated output channels. This modulesupports dual-redundant configurations, ensuring reliable and consistentvoltage outputs for various industrial applications.
Technical specifcations for AAV542-S00
Model: AAV542-S00
Suffix Codes:
-S: Standard type
-5: With no explosion protection
-E: With explosion protection
-0: Basic type
-3: With lSA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes:
/K4A00: With KS Cable Interface Adapter [Model: ATK4A-00]
/A4S00: With Pressure Clamp Terminal Block for Analog [Model: ATA4S00]
/A4S10: With Pressure Clamp Terminal Block for Analog (surgeabsorber)[Model: ATA4S-10]
/A4D00: With Dual Pressure Clamp Terminal Block for Analog [Model:ATA4D-00]
/A4D10: With Dual Pressure Clamp Terminal Block for Analog(surgeabsorber) [Model: ATA4D-10]
/CCC01: With Connector Cover for MlL Cable [Model: ACCC01]
Weight and Dimensions
Weight: 0.2 kg
Dimensions:130 mmx107.5 mmx32.8 mm
Features
Number of Output Channels:16,non-isolated
Output signal: -10 to +10 V
Allowable Load Resistance: 10 kΩ or larger
Accuracy: The larger of ±0.3 % FS or +12 mV
Data Update Period:10 ms
Output step Response Time: 40 ms
Temperature Drift: The larger of ±0.1 %/10 'C or +10 mV/10°C
Maximum Current Consumption: 450 mA (5 V DC)
External Connection: Pressure clamp terminal, KS cable, MlL connector cable
