Siemens 6ES7131-4BD01-0AB0 Technology modules

Siemens 6ES7131-4BD01-0AB0 4 DI HF 24 VDC SIMATIC DP ET200S

SIMATIC DP, 5 electronic modules for ET 200S, 4 DI High Feature 24 V DC, 15 mm width, with param. input delay Diagnostics encoder short circuit with SF LED (group fault) 5 units per packing unit.

Technical specifcations for 6ES7131-4BD01-0AB0

Product Line: SIMATIC DP, ET200S, El-Mod., 4DI HF, DC 24V, 5PC

Number of Digital Inputs: 4 DI High Feature 24 V DC

Power Supply: 24 V DC

Dimensions (WxHxH): 15 x 81 x 52 mm

Weight: 35 g

Supply voltage

Rated value (DC): 24 V; From power module

Reverse polarity protection: Yes

Input current

from supply voltage L+, max: Dependent on encoder

from backplane bus 3.3 V DC, max.: 10 mA

Encoder supply

Type of output voltage: min. L+ (-0.5 V), under load

Short-circuit protection: Yes; Electronic

Output current

● Rated value: 500 mA

● Permissible range, lower limit: 0 mA

● Permissible range, upper limit: 500 mA

Power loss

Power loss, typ: 0.7 W

● Address space per module, max: 1 byte

● with packing: 4 bits

Digital inputs

Number of digital inputs: 4

Input characteristic curve in accordance with IEC 61131, type 1: Yes

Input voltage

● Type of input voltage: DC

● Rated value (DC): 24 V

● for signal "0": -30 to +5 V

● for signal "1": +11 to +30V

Input current

● for signal "1", typ: 8 mA

for standard inputs

— parameterizable: Yes; 0.1 / 0.5 / 3 / 15 ms

— at "0" to "1", min: 0.05 / 0.4 / 2.7 / 14.85

— at "0" to "1", max: 0,15 / 0,6 / 3,3 / 15,15

— at "1" to "0", min: 0.05 / 0.4 / 2.7 / 14.85

— at "1" to "0", max: 0,15 / 0,6 / 3,3 / 15,15

Cable length

● shielded, max: 1 000 m

● unshielded, max: 600 m

Connectable encoders

● 2-wire sensor: Yes

— Permissible Quiescent Current (2-Wire Sensor), Max: 1.5 mA

Interrupts/diagnostics/status information

Diagnostics function: Yes

Diagnoses

● Short-circuit: Yes; Short-circuit of outputs to ground; module by module

Diagnostics indication LED

● Group error SF (red): Yes

● Status of digital input indicator (green): Yes; per channel

Parameters

Remark: 3 bytes

Diagnostics short-circuit: Disable / enable

● between the channels: Full

● between the channels and backplane bus: Yes

Isolation

Isolation tested with: 500 V DC

Dimensions

Width: 15 mm

Height: 81 mm

Depth: 52 mm

Weights

Weight, approx: 35 g
