6ES7131-4BD01-0AA0

Siemens 6ES7131-4BD01-0AA0 Technology modules

Siemens 6ES7131-4BD01-0AA0 4 DI ST 24 VDC SIMATIC DP ET200S

  • Item no.:

    6ES7131-4BD01-0AA0
  • Payment:

    T/T, Western Union
  • Market price:

    $66
  • Price:

    $99
  • Product origin:

    GERMANY
  • Color:

    Original and Brand New
  • Goods stock:

    20
  • Lead Time:

    In stock/1-3days

Siemens 6ES7131-4BD01-0AA0 4 DI ST 24 VDC SIMATIC DP ET200S



SIMATIC DP, 5 electronic modules for ET 200S, 4DI standard 24 V DC, 15 mm width, 5 units per packing unit.



Technical specifcations for 6ES7131-4BD01-0AA0



Product Line: SIMATIC DP, ET200S, El-Mod., 4DI ST., DC 24V, 5pcs.

Number of Digital Inputs: 4 DI standard 24 V DC

Power Supply: 24 V DC

Dimensions (WxHxH): 15 x 81 x 52 mm

Weight: 35 g



Supply voltage

Rated value (DC): 24 V; From power module

Reverse polarity protection: Yes



Input current

from supply voltage L+, max: Dependent on encoder

from backplane bus 3.3 V DC, max: 10 mA



Encoder supply

Type of output voltage: min. L+ (-0.5 V), under load



Output current

● Rated value: 500 mA

● Permissible range, lower limit: 0 mA

● Permissible range, upper limit: 500 mA



Power loss

Power loss, typ: 0.7 W



Address area

● Address space per module, max: 1 byte

● with packing: 4 bits



Digital inputs

Number of digital inputs: 4

Input characteristic curve in accordance with IEC 61131, type 1: Yes



Input voltage

● Type of input voltage: DC

● Rated value (DC): 24 V

● for signal "0":  -30 to +5 V

● for signal "1": +15 to +30 V



Input current

● for signal "1", typ: 7 mA; at 24 V



Input delay (for rated value of input voltage)

— parameterizable: Full

— at "0" to "1", min: 2 ms; Typically 3 ms

— at "0" to "1", max: 4.5 ms

— at "1" to "0", min: 2 ms; Typically 3 ms

— at "1" to "0", max: 4.5 ms



Cable length

● shielded, max: 1 000 m

● unshielded, max: 600 m



Connectable encoders

● 2-wire sensor: Yes

— Permissible Quiescent Current (2-Wire Sensor), Max: 1.5 mA



Interrupts/diagnostics/status information

Diagnostics function: Full



Alarms

● Hardware interrupt



Diagnoses

● Short-circuit



Diagnostics indication LED

● Group error SF (red): Full

● Status of digital input indicator (green): Yes; per channel



Parameters

Remark: 1 byte



Potential separation digital inputs

● between the channels: Full

● between the channels and backplane bus: Yes



Isolation

Isolation tested with: 500 V DC



Dimensions

Width: 15 mm

Height: 81 mm

Depth: 52 mm



Weights

Weight, approx: 35 g
