Schneider TSXDSY08R4D Discrete Output Module

Schneider TSXDSY08R4D MODICON PREMIUM DISCRETE OUTPUT MODULE - 8 O RELAY

The Schneider TSXDSY08R4D is a discrete output module belonging to the Modicon Premium automation platform by Schneider Electric. It is designed to control external devices like lamps, motors, and solenoids based on signals received from a programmable logic controller (PLC).

Technical specifcations for TSXDSY08R4D

Main

Range of Product: Modicon Premium Automation platform

Product or Component Type: Discrete output module

Discrete output number: 8

Discrete output type: Relay protected

Discrete output voltage: 24...120 V DC EN/IEC 61131-2 19...143 V

Complementary

[Ith] conventional free air thermal current: 5 A

Response time: < 10 ms (activation); < 15 ms (deactivation)

Contacts type and composition: 2 x 2 C/O + 2 x 2 NO

Output overvoltage protection: RC circuit and Ge-Mov

Output overload protection: 6.3 A, interchangeable fuse per common fast blow

Short-circuit protection: 6.3 A, interchangeable fuse per common fast blow

isalotion resistance: > 10 MOhm 500 V

Power dissipation: (0.25 W + 0.24 W x No of outputs at state 1)

Electrical durability

1000000 cycles DC-12 100 W 48 V resistive

1000000 cycles DC-12 220 W 100...120 V resistive

1000000 cycles DC-12 50 W 24 V resistive

1000000 cycles DC-3 100 W 48 V inductive

1000000 cycles DC-3 220 W 100...120 V inductive

1000000 cycles DC-3 50 W 24 V inductive

2000000 cycles DC-3 110 W 100...120 V inductive

2000000 cycles DC-3 20 W 24 V inductive

2000000 cycles DC-3 50 W 48 V inductive

300000 cycles DC-12 100 W 24 V resistive

300000 cycles DC-12 200 W 48 V resistive

300000 cycles DC-12 440 W 100...120 V resistive

Marking: CE

Electrical connection: Screw terminal block

Current consumption: 55 mA 5 V DC; 80 mA 24 V DC rack

Module format: Standard

Net Weight: 0.82 lb(US) (0.37 kg)

Environment

Dielectric strength: 2000 V 50/60 Hz 60 s

Ambient Air Temperature for Operation: 32…140 °F (0…60 °C)

Ambient Air Temperature for Storage: -13…158 °F (-25…70 °C)

Operating altitude: 0...6561.68 ft (0...2000 m)

protective treatment: TC

IP Degree of Protection: IP20

Pollution degree: 2

Relative Humidity

10…95 % without condensation for operation

5…95 % without condensation for storage
