Schneider 140CPU31110 Unity processor-Modicon Quantum

Schneider 140CPU31110 MODICON QUANTUM PROCESSOR UNITY PROCESSOR MODICON QUANTUM - 548 KB - 66 MHZ

Schneider Electric introduces the 140CPU31110, a high-performance CPU module designed to drive efficiency and reliability in industrial automation systems. With many features and capabilities, this CPU module epitomizes Schneider Electric's commitment to innovation and quality.

Technical specifcations for 140CPU31110

Dimensions: 31 cm x 17 cm x 5 cm

Weight: 0.7 kg

Description: SIEMENS 6ES7326-1BK01-0AB0 | SM326 Digital Input Module

Main

Range of Product: Modicon Quantum automation platform

Product or Component Type: Unity processor

Complementary

Clock frequency: 66 MHz

Number of slots: 16; 4; 10; 2; 6

Number of racks: 2 - local

Number of distributed I/O station: 63 1 3 Modbus Plus

Number of remote I/O station: 31 - 2 S908 remote I/O; 0 - 0 ethernet remote I/O

Discrete I/O number: Unlimited (27 slots max) - local; 31744 inputs, 31744 outputs - remote; 8000 inputs, 8000 outputs - distributed - per network Modbus Plus

Analogue I/O number: Unlimited (27 slots max) - local; 500 inputs, 500 outputs - distributed - per network Modbus Plus; 1984 inputs,1984 outputs - S908 remote I/O

Application specific I/O: High-speed interrupt inputs; Counter; Accurate time stamping; Serial link

Number of optional modules: 2 Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)

Maximum number of connections: 1 USB; 2 AS-Interface - distributed; 2 Ethernet TCP/IP - local; 2 Modbus Plus - local; 2 Modbus RS232/485 Modbus/ASCII); 2 Profibus DP - local; 4 AS-Interface - remote

Integrated connection type: 1 Modbus Plus; 2 Modbus

Checks: Process control

Memory description: Internal RAM 548 kB

Switch Function: Slide switch communication port : ASCII/RTU/Memory; Slide switch memory port/off

Application structure: 1 cyclic/periodic master task -; 1 periodic fast task -; 16 timer interrupt tasks -; 64 I/O interrupt tasks -; 64 interrupt tasks -; No auxiliary task - Execution time per instruction: 0.1...0.27 µs floating points; 0.1...0.27 µs on fixed-point arithmetic; 0.12...0.585 µs Boolean; 0.12...0.585 µs on word

Number of instructions per ms: 1.86 Kinst/ms 100 % Boolean; 2.49 Kinst/ms 65 % Boolean and 35 % numerical

System overhead: 0.2 ms fast task; 1 ms master task

Bus current requirement: 1800 mA

Local signalling:

for communications are active on the Modbus Plus port (Modbus Plus) 1 LED (green)

for communications are active on the Modbus port (Modbus) 1 LED (green)

for CPU has been started and is solving logic (RUN) 1 LED (green)

for CPU has passed the power-up diagnostic tests (READY) 1 LED (green)

for write-protected memory (memory port) 1 LED (orange)

for battery needs replacing or is not present (BAT LOW) 1 LED (red)

for communications error on the Modbus Plus port (ERROR A) 1 LED (red)

Electrical connection:

1 female connector SUB-D 9 for connecting to the Modbus Plus network

2 female connectors SUB-D 9 for connecting to the Modbus bus

Environment

Product Certifications: CSA; CE;UL

Standards: HazLoc
