Allen Bradley 2711P-T7C4D6 PowerFlex
The 2711P-T7C4D6 operator interface terminal is a small touchscreen terminal from the Allen-Bradley/Rockwell Automation Panelview Plus 700 series. It has no physical keys because its display screen is also a touchscreen that can be activated by hand or with a stylus that is not too heavy or sharp. The 2711P-T7C4D6 operator interface terminal can display its data with color graphics. However, its touchscreen is only 7 inches wide. The 2711P-T7C4D6 operator interface terminal has 128 MB of memory and it operates at 18 to 32 Volts DC.
Technical specifications for 2711P-T7C4D6
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-T7C4D6
Product Line:Panelview Plus 700
Display Size:6.5 in.
Display Color:Color
Input Type:Touchscreen
Communication:Ethernet and RS-232
Input Power:18-32 VDC
Memory:128 MB
Backlight:2711P-RL7C2
Communication Cable:1761-NET-ENI
Shipping Weight:8 lbs.
Shipping Dimensions:14 x 11 x 8 in
SeriesS:eries A, B, C, D, E, F, G
UPC:10612598349682
Product Lifecycle Status*:Discontinued/Obsolete
Description
The discontinued Allen Bradley Panelview Plus 700 2711P-T7C4D6 is an operator terminal that enables the user to interface with their machine. This HMI has a 6.5 in. Color Display. The user is able to control the HMI using the Touchscreen to input information and data. This unit is powered using 18-32 VDC power. This unit has the following internal memory: 128 MB. If applicable this unit has an internal backlight replacement part number of 2711P-RL7C2. The approximate shipping weight and dimensions are 8 lbs. and 14 x 11 x 8 in. EtherNet/IP (Ethernet Industrial Protocol) is an open industrial network that supports real time I/O messaging, as well as message exchange. The Ethernet port connects to a controller on an EtherNet/IP network by using both the network and standard Ethernet connections. This port can work with application transfers and printing as well. The EtherNet/IP screen displays and allows the user to modify some of the EtherNet/IP communication settings for a PanelView terminal. The 2711P-RN20 Ethernet communication module is available for the 700 to 1500 terminals if another Ethernet port is required. The module has its own unique IP address. This port has an RJ45, 10/100Base-T connector for network communication and supports MDI/MDI-X connections. The parameters are downloaded with the application.
