Allen Bradley 2711P-B15C6A6 PowerFlex
The 2711P-B15C6A6 operator interface terminal is an Allen-Bradley/Rockwell Automation Panelview Plus 1500 series operator interface terminal. Furthermore, it comes with both a touchscreen and a keypad that the operators can use to control the terminal itself and the machines that the terminal is installed in. The 2711P-B15C6A6 operator interface terminals keypad has function keys which can be programmed and its 15-inch touchscreen has color graphics. The input voltage rating of the terminal is between 100 and 240 Volts AC. The 2711P-B15C6A6 operator interface terminals operating temperature range is from 32 to 131 degrees Fahrenheit at 5 to 95% non-condensing relative humidity.
Technical specifications for 2711P-B15C6A6
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-B15C6A6
Series:Panelview Plus 1500
Input Method:Keypad and Touchscreen Input
Communicaion Ports:DH+/RIO/DH-485 Communication ports
Power:VAC Input
Display Type:15 in. Color Display
Features:128 MB
Product Lifecycle Status*:Discontinued/Obsolete
Description
The Allen-Bradley 2711P-B15C6A6 PanelView Plus 1500 Terminal is an interface device in the PanelView Plus operator interface terminal series that gives users an easy and complete interface with their machines, for monitoring and control. The 2711P-B15C6A6 offers the users a vivid display of industrial operations via it 15-inch widescreen with a field replaceable backlight, and it comes in a modular design with base-configured modules for fast and easy installation. The 2711P-B15C6A6, unlike most operator interface in the series, offers parameter input and easy setup through its stainless domed keypad with Alpha-numeric, navigational, and 40 function (F1 through F20, K1 through K20) keys, and it also allows for input via its analog resistive touchscreen that is operable with bare fingers, gloved fingers, or a plastic stylus. Users can graphically view the machine operations via its LCD, with 304mm x 228mm (12.0in x 9.0in) display dimensions and 1024 x 768 display resolution, and it provides a display brightness of 300 cd/m2 Nits.
FAQ & Contact:
Q: Are you a trading company or a manufacturer?
A: We are a trading company.
Q: What is your lead time?
A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.
Q: Does your company provide samples? Is it free or do you charge extra?
A: It depends on the goods you need and the quantity you order.
Q: What are your terms of payment?
A: 100% T/T before shipping. If the quantity is large, we can negotiate.
