Allen Bradley 2711P-RP8A PowerFlex 700 Brand new

Allen Bradley  2711P-RP8A   PowerFlex

The Allen-Bradley 2711P-RP8A is a Logic module that is compatible with PanelView Plus 6 operator terminals. This logic module is compatible for PanelView Plus 6 700-1500 operator terminals. It has a Random Access Memory (RAM) amounting to 512 MB and Flash memory amounting to 512 MB. This logic module has One (1) serial, Two (2) USB and One (1) Ethernet interface ports.

Technical specifications for 2711P-RP8A

Communication：One (1) RS232; One (1) Ethernet; Two (2) USB

Product Type：Logic Module

Brand：Allen-Bradley

Manufacturer:Rockwell Automation

Product Family:PanelView Plus 6 Operator Terminal

Memory:512 MB Flash/ 512 MB RAM (79 MB free user memory)

Compatible Hardware:PanelView Plus 6 700-1500

Status indicators:Red and Green LED

Interfaces:Ethernet port, serial port, two USB ports, CompactFlash card slot

Marine Certified:Yes

Operating Temperature:0-55 Degree Celsius

Power input:100-240VAC

Frequency:50-60 Hz

Power Dissipation:160VA

Part Number/Catalog No.：2711P-RP8A

Series：PanelView Plus 6- 7001500 Logic Modules

Nonvolatile Memory：512 MB

RAM Memory：512 MB

Input：AC

Description:

The Allen-Bradley 2711P-RP8A is a logic module with 512MB of non-volatile RAM that uses AC voltage as a power source. It is compatible with PanelView Plus 6 700-1500 operator terminals. Due to its adjustable memory and capability in complex applications, this logic module can work in harsh environments. The Network interface for the 2711P-RP8A can connect to it with the CompactFlash, Ethernet, and USB ports available in this logic module. The module has flashing indicators for process identification and there are provisions to perform control panel operations or even connect to third-party applications at the click of a button. Although there are standard features like a command shell, a common dialog box, and a PDF reader with the 2711P-RP8A, there are also extended features like remote desktop connectivity, Media Player options, and a Wordpad Text editor. Make sure to connect the protective earth terminal to a low impedance ground. To avoid the loss of saved settings, make sure to connect the display module when the 2711P-RP8A is powered off.
