Allen Bradley 2711P-K4M3D PowerFlex
The Allen-Bradley 2711P-K4M3D is a PanelView Plus 400 Grayscale terminal. This Human Machine Interface (HMI) device is powered by an external supply voltage of 18-30VDC. It has a 3.8-inch Grayscale passive matrix, film compensated super-twist nematic (FSTN). It has embedded keypad and operator interface and One (1) RS232 port, One (1) Ethernet communication ports and One (1) USB communication interface.
Technical specifications for 2711P-K4M3D
BrandAllen-Bradley
Part Number/Catalog No.2711P-K4M3D
Display Size3.8 inches
ManufacturerRockwell Automation / Allen-Bradley
Product Family:PanelView Plus Graphic Terminals
Display Type:Monochrome Passive Matrix, Film Compensated Super-Twist Nematic (FSTN)
Display Area:78 x 59 mm (3.07 x 2.32 in)
Resolution:320 x 240, 16-levels gray
Backlight:LED
Keypad:8 function keys (F1…F8), Numeric input, navigation
System Memory:5MB (Series A); 10 MB (Series B or later)
Communication ports:One (1) Ethernet; One (1) RS-232, One (1) USB
External storage:Secure Digital (SD) card, cat. no.1784-SDx, supported by hot-swappable SD card slot USB flash drive that is supported by high-speed, hot-swappable, 2.0 USB host port
Input Voltage range:18 to 32 VDC; 24VDc nominal
Power Consumption:25 W max (1.0 A at 24V DC
Weight:562 g (1.24 lb)
Temperature, operating0…55 °C (32…131 °F)
Heat dissipation85 BTU/hr
Shock, operating15 g at 11 ms
Product LinePanelview Plus 400
Display ColorGrayscale
Input TypeKeypad
CommunicationDH-485 Port
Input PowerDC
Memory64 MB
SeriesA, B, C, D, E
Product Lifecycle Status*Discontinued/Obsolete
Description
The Allen-Bradley 2711P-K4M3D is a PanelView Plus 400 operator terminal. This operator terminal is powered by an external supply voltage range of 18-30VDC with nominal value of 24VDC. This operator terminal is part of the larger product family of the 2711P PanelView Plus operator terminals which are visualization components that supports installation near (local) or away (remote) from the process being controlled.
The 2711P-K4M3D may also be called as a Human Machine Interface (HMI). This is the general term used in the industry that may refer to any brand of HMI that performs real-time monitoring and control of process. Specifically, the 2711P-K4M3D provides process visualization via the 3.8-inch display Grayscale passive matrix, film compensated super-twist nematic (FSTN) screen which has a resolution of 320 x 240 and display area 77 x 58 mm (3.0 x 2.3 in.). It has a LED backlight with expected lifespan of CCFL 50,000 hours life, min. This backlight is not replaceable.
