Allen Bradley 2711P-K4M5A PowerFlex
The Allen-Bradley 2711P-K4M5A terminal is a control terminal from the Panelview Plus 400 series. It has a screen that is only 4 inches wide and that only supports monochrome graphics. The 2711P-K4M5A control terminal is equipped with a keypad as its control method. It operates on AC power and it has an RS-232 type of communication port. The 2711P-K4M5A control terminal has 64 MB of memory and an operating temperature range of 32 to 131 degrees Fahrenheit.
Technical specifications for 2711P-K4M5A
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2711P-K4M5A
Product LinePanelview Plus 400
Display Size3.5 inch
Display ColorGrayscale
Input TypeKeypad
CommunicationRS-232 Port
Input PowerAC
Memory64 MB
SeriesA, B, C, D, E
Product Lifecycle Status*Discontinued/Obsolete
Description
The Allen-Bradley 2711P-K4M5A PanelView Plus 400 Standard Terminal is a Human Machine Interface device in the Allen-Bradley PanelView Plus Series of operator interface devices, which provides users with interfaces to their machinery for maintenance and control. The 2711P-K4M5A comes with base-configured modules, AC power supply module, field replaceable display module, integral communication ports with supports for additional communication modules, and it has a compact design which allows for easy configuration and setup. It provides graphical visualization of the machine operations using it 3.8-inch wide passive matrix grayscale graphics display, with film compensated super-twist nematic (FSTN), and a with a display area of 3.0 x 2.3 inches and a resolution of 320 x 240 pixel. It also offers a field-replaceable LED backlight with 120 cd/m2 (Nits) of display brightness and with 50,000 hours of life expectancy.
