Allen Bradley 2711P-K15C15A2 PowerFlex
The 2711P-K15C15A2 operator interface terminal is an AC-powered Allen-Bradley/Rockwell Automation Panelview Plus 1500 series operator interface terminal. Its input voltage rating is between 100 and 240 Volts AC. The 2711P-K15C15A2 operator interface terminal is controlled by a keypad that has programmable function keys. The operators can use these function keys to save their most common application functions. The 2711P-K15C15A2 operator interface terminal can support color graphics on its 15-inch display screen.
Technical specifications for 2711P-K15C15A2
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-K15C15A2
Series:Panelview Plus 1500
Input Method:Keypad Input
Communicaion Ports:Controlnet Communication Port
Power:VAC Input
Display Type:15 in. Color Display
Features:128 MB
Product Lifecycle Status*:Discontinued/Obsolete
Description
The Allen Bradley 2711P-K15C15A2 is an integrated-display industrial computer from the PanelView Plus family. Its equivalent from the PanelView Plus 6 series is the 2711P-K15C4A8. The main components of the factory-assembled 2711P-K15C15A2 include a display and a logic module. For applications requiring additional network interfaces, communication modules are available as options. The 2711P-K15C15A2 is equipped with 512 MB of non-volatile user memory (79 MB is free for applications) and 512 of MB RAM. Storage can be increased by inserting a hot-swappable SD card in the SD card slot or by connecting the USB flash drives to the USB ports.
The size of the display on the 2711P-K15C15A2 is 15 inches (with a 304 x 228 mm display area). The display supports a 1024 x 768 resolution and 18-bit color graphics. The display is rated at 300 nits. The display backlight is field replaceable and is rated for 50,000 hours (at 25 ºC). The 2711P-K15C15A2 includes the following four integrated communications ports: one 10/100 FastEthernet port, one RS-232 serial port, and two USB ports (for connecting USB flash drives, mouse, keyboard or printer). The HIM on the 2711P-K15C15A2 is a 32-key keypad. The 2711P-K15C15A2 runs on 100-240V AC power and it consumes a maximum of 160VA of power (typical power consumption is 65VA).
FAQ & Contact:
Q: Are you a trading company or a manufacturer?
A: We are a trading company.
Q: What is your lead time?
A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.
Q: Does your company provide samples? Is it free or do you charge extra?
A: It depends on the goods you need and the quantity you order.
Q: What are your terms of payment?
A: 100% T/T before shipping. If the quantity is large, we can negotiate.
