Allen Bradley 2711P-T15C6D1 PowerFlex
The 2711P-T15C6D1 operator interface terminal is a DC-powered operator interface terminal. It has been designed and manufactured by Allen-Bradley/Rockwell Automation as part of the Panelview Plus 1500 series. The nominal voltage rating of the 2711P-T15C6D1 operator interface terminal is 24 Volts DC while its input voltage rating is 18 to 30 Volts DC. The touchscreen that controls this terminal is 15 inches wide and it can support color graphics. The 2711P-T15C6D1 operator interface terminal comes with DH+, DH-485, and RIO communication ports for connecting to other devices.
Technical specifications for 2711P-T15C6D1
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-T15C6D1
Series:Panelview Plus 1500
Input Method:Touchscreen Input
Communicaion Ports:DH+/RIO/DH-485 Communication ports
Power2:4 VDC Input
Display Type:15 in. Color Display
Features:64 MB
Product Lifecycle Status*:Discontinued/Obsolete
Description
The ‘Series A’ 2711P- T15C6D1 module is an Allen-Bradley PanelView Plus 1500 module. It has a 15-inch color operator touchscreen. It also has a memory capacity of 64 MB of flash memory. It can also accommodate a 64-MB RAM. The 2711P-T15C6D1 works simply, quickly, and efficiently. This Allen-Bradley PanelView module comes with a Standard Communication system including an Ethernet port and an RS-232 port. There is a variety of Series A from Rockwell Automation products and the 2711P- T15C6D1 has 24V DC input power. The 2711P-T15C6D1 module can be converted from an existing PanelView Plus/PanelView Plus CE device to a new PanelView Plus 6 device which is called the 2711P-T15C4D8. The PanelView Plus 1500 touchscreen is ranked among the best touchscreen controllers on the market when it comes to graphics terminals. The touchscreen technology is highly advanced and one of the most intuitive systems available. This product can easily pick up the bulk of the work when a network or application has been automated by this product. The 2711P-T15C6D1 is also very flexible because it can be programmed according to a variety of specifications. It will, therefore, allow for controlling, monitoring, and displaying of the information about the application status graphically.
