Allen Bradley 2711P-T12C15A7 PowerFlex
The Allen-Bradley 2711P-T12C15A7 terminal is an operator interface terminal that has been designed and manufactured as part of the Allen-Bradley/Rockwell Automation Panelview Plus 1250 series. It operates with an input voltage rating between 85 and 264 Volts AC. The 2711P-T12C15A7 operator interface terminal is controlled by a 12.1-inch touchscreen. This touchscreen can display its menu screens and application data with full color graphics. The 2711P-T12C15A7 operator interface terminal can operate at a temperature range from 0 to 55 degrees Celsius and at a non-condensing relative humidity range between 5 and 95%.
Technical specifications for 2711P-T12C15A7
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-T12C15A7
Product Line:Panelview Plus 1250
Display Size:12.1 inches
Input Type:Touchscreen
Display Type:Full Color
Communication:ControlNet
Input Power:85-264 Volts AC
Memory:256 Megabytes
Shipping Dimensions:11.12 x 14.3 x 2.17 inches
Product Lifecycle Status*:Discontinued/Obsolete
Description
The 2711P-T12C15A7 is a Panelview Plus 1250 12.1 inches color display terminal with a touchscreen. The 2711P-T12C15A7 is manufactured by Allen-Bradley and it comes with ControlNet communication AC power and a CE Logic Module with 256 MB of storage capacity. As indicated, the input type for the 2711P-T12C15A7 is a touch-screen while the display type is full color.
The 2711P-T12C15A7 is designed using an open architecture and it runs the .Net Compact Framework. The supported file format for the 2711P-T12C15A7 is Datalight Reliance with FAT support. The CPU included with the 2711P-T12C15A7 is the x86 while the inbuilt RAM is a 512 MB DDR2 chip. The 2711P-T12C15A7 also comes with real-time clock feature. There are various interfaces that come with the 2711P-T12C15A7. These include 1 secure digital high capacity slot that supports 1784-SDX cards. Then there are 2 USB-A ports which run at 2.0 high speed. For communication, the 2711P-T12C15A7 comes with Ethernet Support, RS-232, ControlNet, DH+™, and DH-485 support. The ControlNet, DH+™, and DH-485 are optional add-on Communication modules. For the input power, the 2711P-T12C15A7 comes with isolated DC Voltage or AC Voltage ports. The environmental specifications for the 2711P-T12C15A7 include an operating temperature of 0 to 55 degrees Celsius while the storage or transportation temperature is -25 to 70 degrees Celsius. The relative humidity is 5 to 95%, non-condensing. The 2711P-T12C15A7 uses modular components that allow for flexible configuration, installation, and upgrades.
