Allen Bradley 2711P-B12C15D7 PowerFlex
The Allen-Bradley 2711P-B12C15D7 terminal is an operator interface terminal. It has been manufactured as part of the Panelview Plus 1250 series. The 2711P-B12C15D7 operator interface terminal is one of the Panelview Plus terminals that is equipped with both a touchscreen and a keypad as input options. The touchscreen is also a color display that is 12 inches wide. The 2711P-B12C15D7 operator interface terminal operates with 18 to 32 Volts DC input power.
Technical specifications for 2711P-B12C15D7
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-B12C15D7
Product Line:Panelview Plus 1250
Display Size:12.1 inches
Input Type:Touchscreen and Keypad
Display Type:Full Color
Communication:ControlNet
Input Power:18-32 Volts DC
Memory:256 Megabytes
Shipping Dimensions:11.12 x 16.36 x 2.17 inches
Product Lifecycle Status:*Discontinued/Obsolete
Description
The Allen-Bradley 2711P-B12C15D7 is a PanelView Plus 1250 CE color terminal with a 256 MB Flash storage memory, as well as 256 RAM, and it comes with an extended memory option. The input of this terminal is done via its keypad and analog resistive touchscreen and its available communication options are Ethernet, ControlNet, and RS-232 ports. The screen installed on the 2711P-B12C15D7 terminal is a 12.1-inch 18-bit color active matrix thin film transistor (TFT) type with a resolution of 800 x 600 and a total display area of 9.7 x 7.2 inches. It comes with a backlight that is field replaceable and has a 300 Nits luminance that can last an average of 50,000 hours. The keypad input of the 2711P-B12C15D7 terminal has 40 function keys present and it has a stainless steel domed membrane. This DC-powered terminal has an input voltage of 18 to 32V DC, with a 24V DC nominal input voltage, as well as a 70 W or 2.9 A at 24V DC power consumption.
