Allen Bradley 22F-D024N104 PowerFlex
The Allen-Bradley 22F-D024N104 PowerFlex 4M adjustable frequency AC drive. This drive features an input voltage range of 380-480VAC, 3-phase and delivers output voltage of 0-460VAC, 3-Phase, with rated Current of 24.0 A and Power of 11.0 kW (15.0 HP). It has an integral RS485 communication interface.
Specifications
ManufacturerRockwell Automation
Part Number/Catalog No.22F-D024N104
BrandAllen-Bradley
Product Family:PowerFlex 4M Adjustable Frequency AC Drive
Input Voltage:380-480VAC
Input Phase:3-Phase
Input Current:7.5 A
Output Voltage:0-460VAC
Output Current:6.0 A
Output Power:2.2 kW (3.0 HP)
I/O:Discrete Inputs: Five (7) Sink / Source Discrete Outputs: One (1) Form C Contacts Analog Input: One (1) Analog Input 0-10VDC; 0- 20mA
Installation:Panel Mount
Enclosure Rating:IP20 / NEMA UL Open Type
Frame:C
Control Method:Volts / Hertz Control performance
Built-in communication port:RS485
Optional communication protocols:BacNet; LonWorks; ProfiBus; Ethernet; DeviceNet; ControlNet
Product Line：Powerflex 4M
Amperage：24
Wattage：11 Kilowatt
Enclosure Type：Open- IP20
Input Power：480 Volts- Alternating Current
Phase：Three-Phase
Filter：Without CE Compliant Filter
Horsepower：15 Horsepower
Communication：RS-485 Port
Description:
Part #：22F-D024N104
Category：Drives
Subcategory：Drive
Weight：10.60 lbs
Drive Type：PowerFlex 4M,
Voltage Rating：480 VAC, 3 PHASE
Rating：24 AMP, 5.5 kW, 7.5 HP,
Enclosure：PANEL MOUNT - IP 20 NEMA TYPE OPEN
HIM：FIXED KEYPAD
Emission Class：NOT FILTERED
Brake：STANDARD BRAKE
