Allen Bradley 20BC170A3AYNANC0 AC Drive New and Original High quality

Allen Bradley 20BC170A3AYNANC0 PowerFlex 700 AC Drive 20B

Manufacturer : Rockwell Automation

Brand :  Allen-Bradley

Part Number/Catalog No. : 20BC170A3AYNANC0

Degree of protection (IP) : IP20

Shock : 15 G peak for 11 ms duration (±1.0 ms)

PWM frequency : 4 kHz @ 400V AC

Vibration : 0.152 mm (0.006 inch) displacement, 1 G peak

Number of analogue outputs : 2

Mains voltage : 400 V

Integrated breaking resistance : No

Brake IGBT : Brake IGBT installed

Internal communication module : No communication module

Input voltage rating : 400V AC, 3-phase, 50 Hz

AC input undervoltage trip : 233V AC @ 380/400V

Bus voltage, nom : 540V DC @ 380/400V

Bus undervoltage shutoff/fault : 305V DC @ 380/400V

Bus overvoltage trip : 810V DC @ 380/400V

Output voltage rating : 0...400V AC @ 380...400V AC, 1-phase

Circuit breaker current rating, max : 500 A @ 400V AC, 3-phase, normal duty

Motor circuit protector current rating, max : 250 A @ 400V AC, 3-phase, normal duty

Output current rating, continuous : 170 A @ 400V AC, 3-phase, normal duty

Output current rating, 1 min : 210 A @ 400V AC, 3-phase, heavy duty

Output current rating, 3 sec : 280 A @ 400V AC, 3-phase, heavy duty

Logic control ride-thru : 0.5 seconds minimum, 2 seconds typical

Brake resistor : No internal brake resistor

Input current rating : 164 A @ 400V AC, 3-phase

Documentation : Manual

Carrier frequency : 2, 4, 8, and 10 kHz. Drive rating based on 4 kHz

Encoder quadrature : 90 degrees, ±27 degrees at 25 °C (77 °F)

AC input overvoltage trip : 570V AC @ 380/400V

Input power rating : 126 kVA @ 400V AC, 3-phase, normal duty

Dual element time delay fuse current rating : 250...375 A @ 400V AC, 3-phase, normal duty

Non-time delay fuse current rating : 250...600 A @ 400V AC, 3-phase, normal duty

Digital input latency, typical : 9.2 ms @ stop signal for SVC motor control

Heat sink thermistor : Monitored by microprocessor overtemp trip

Digital input latency  : 9.2...16.0 ms @ start signal for SVC motor control

Drive to motor power ratio, max : Recommended not greater than 2:1 ratio

FAQ & Contact:

Q: Are you a trading company or a manufacturer?

A: We are a trading company.

Q: What is your lead time?

A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.

Q: Does your company provide samples? Is it free or do you charge extra?

A: It depends on the goods you need and the quantity you order.

Q: What are your terms of payment?

A: 100%  T/T before shipping. If the quantity is large, we can negotiate.

Our Services:

1、 All our products are new and original, and of good quality.

2、  Our prices are very competitive.

3、  We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.

4、  All inquiries will be valued and will reply in 24.

Packing & Delivery:

1)100% brand New and Original Factory Seal!

2)Warranty: 1 year

3)Package: Original packing with cartons.

4)Delivery time: Shipped in 3-7 days after payment

5) All the goods will be tested before shipment.
