Siemens 6GK5788-2AA60-6AA0 Digital modules

Siemens 6GK5788-2AA60-6AA0 SCALANCE W788-2RR

IWLAN DUAL ACCESS POINT SCALANCE W788-2RR, INLY FOR USE IN USA, 2 RADIO INTERFACES, IEEE 802.11 B/G/A/H, INDUSTRIAL WIRELESS LAN WITH RAPID ROAMING (IWLAN RR), 2.4/5 GHZ, UP TO 54MBIT/S, WPA2/802.11I/11E, ALTERNATIVE OPERATION WITH HIPATH WIRELESS CONTROLLER, NOTE NATIONAL APPROVALS, POE, IP65(-20-+60 DGR C), EN50155, SCOPE OF SUPPLY:2XANT 795-4MR, IP67 HYBRID PLUG CONNECTOR, MOUNT. MAT., MAN. ON CD ROM GERMAN/ENGLISH

Technical specifcations for 6GK5788-2AA60-6AA0

Transmission rate

• with W-LAN / maximum: 54 Mbit/s

• with Industrial Ethernet: 10 … 100 Mbit/s

• note: Due to the simultaneous use of several radio channels, a transmission rate of 108 Mbit/s is possible (turbo mode)

Interfaces

Number of electrical connections

• for network components and terminal equipment: 1

• for power supply: 1

• for redundant power supply: 1

Design of electrical connection

• for network components and terminal equipment: Hybrid socket, RJ45 integrated

• for power supply: M12 interface (4-pole, A-coded), hybrid socket, PoE

design of the removable storage / C-PLUG: Yes

Interfaces / wireless

Number of radio cards / permanently installed: 2

Number of electrical connections / for external antenna(s): 4

Design of the electrical connection / for external antenna(s): R-SMA female (socket)

Product property / external antenna can be mounted directly on device: Yes

Supply voltage, current consumption, power loss

Type of voltage / of supply voltage: DC

Supply voltage

• 1 / from M12 Power Connector (A-coded) for redundant power supply: 24 V

• 2 / from M12 Power Connector (A-coded) for redundant power supply: 48 V

• from Power-over-Ethernet according IEEE802.3at for type 1 and IEEE802.3af: 48 V

Current consumed

• at 24 V / with DC / typical: 0.295 A

• at 48 V / with DC / typical: 0.15 A

• with Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af / typical: 0.15 A

Active power loss

• at 24V / for DC / typical: 9 W

• at 48 V / with DC / typical: 9 W

• with Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af / typical: 9 W

Permitted ambient conditions

Ambient temperature

• during operating: -20 … +60 °C

• during storage: -40 … +70 °C

• during transport: -40 … +70 °C

Relative humidity / at 25 °C / without condensation / during operating / maximum: 100 %

Design, dimensions and weight

Width / of enclosure / without antenna: 125 mm

Height / of enclosure / without antenna: 88 mm

Depth / of enclosure / without antenna: 108 mm

Net weight: 1.05 kg

Type of mounting

• S7-300 rail mounting: Yes

• wall mounting: Yes

Wireless frequencies

Radio frequency

• for WLAN in 2.4 GHz frequency band: 2.41 … 2.48 GHz

• for WLAN in 5 GHz frequency band: 4.9 … 5.8 GHz
