Siemens 6ES7132-4BD01-0AA0 Electronics module for ET 200S, 8 DO 24 V DC/0.5 A
Electronics module for ET 200S, 8 DO 24 V DC/0.5 A, 15 mm width, 1 unit per packing unit
Technical specifcations for 6ES7132-4BD01-0AA0
Supply voltage
Reverse voltage protection: Yes
Load voltage L+
● Rated value (DC): 24 V
● Reverse polarity protection: Yes
Input current
from load voltage L+ (without load), max: 5 mA; Per channel
from backplane bus 3.3 V DC, max: 10 mA
Power loss
Power loss, typ: 1.5 W
Address area
Address space per module
● Address space per module, max: 1 byte
Digital outputs
Type of digital output: Source output (PNP, current-sourcing)
Number of digital outputs: 8
Short-circuit protection: Yes
● Response threshold, typ: 1.5 A
Limitation of inductive shutdown voltage to: Typ. L+ (-55 to -60 V)
Controlling a digital input: Yes
Switching capacity of the outputs
● on lamp load, max: 5 W
Load resistance range
● lower limit: 48 Ω
● upper limit: 3 400 Ω
Output voltage
● for signal "1", min: L+ (-1.0 V)
Output current
● for signal "1" rated value: 0.5 A
● for signal "1" permissible range, min: 7 mA
● for signal "1" permissible range, max: 600 mA
● for signal "0" residual current, max: 0.3 mA
Output delay with resistive load
● "0" to "1", max: 300 µs
● "1" to "0", max. 600 µs
Parallel switching of two outputs
● for uprating: No
● for redundant control of a load: Yes
Switching frequency
● with resistive load, max: 100 Hz
● with inductive load, max: 2 Hz
● on lamp load, max: 10 Hz
Total current of the outputs
● Current per module, max: 4 A
Cable length
● shielded, max: 1 000 m
● unshielded, max: 600 m
Interrupts/diagnostics/status information
Diagnostics function: No
Diagnostics indication LED
● Status indicator digital output (green): Yes
Parameter
Remark: 3-byte parameter (not accessible for the user)
Potential separation
Potential separation digital outputs
● between the channels: No
● between the channels and backplane bus: Yes
Isolation
Isolation tested with: 500 V DC
Dimensions
Width: 15 mm
Height: 81 mm
Depth: 52 mm
Weights
Weight, approx: 40 g
