Schneider 140CPU67160S Unity Hot Standby Processor

Schneider 140CPU67160S MODICON QUANTUM UNITY HOT STANDBY PROCESSOR 1024 KB - 266 MHZ

The Schneider Electric 140CPU67160s represents a pinnacle in CPU technology, designed to meet the demanding requirements of industrial automation systems. As a critical component within such setups, this CPU offers advanced features and capabilities aimed at ensuring seamless operation and efficient management of processes.

Technical specifcations for 140CPU67160S

Dimensions: 32.5 cm x 18.5 cm x 11 cm

Weight: 1.4 kg

Description: Schneider Electric 140CPU67160S Unity Security Processor

Main

Range of Product: Modicon Quantum automation platform

Product or Component Type: Unity safety processor

Software Designation: Unity Pro XL safety

Backup type: Lithium battery 990XCP98000

Complementary

Clock frequency: 266 MHz

Number of slots: 10; 2; 16; 6; 3; 4

Number of racks: 1 - local

Number of remote I/O station: 31 - 1 remote

Discrete I/O number:

Unlimited (13 slots max) - local - forbidden in Hot Standby application

31744 inputs, 31744 outputs - remote

Analogue I/O number:

Unlimited (26 slots max) - local - forbidden in Hot Standby application

1984 inputs,1984 outputs - remote

Number of optional modules: 6 Ethernet 140NOE77111

Maximum number of connections:

1 Modbus Plus - local

1 Modbus RS232/485 Modbus/ASCII)

1

1 Ethernet TCP/IP - local

6 USB - local

Integrated connection type:

1 Modbus local

1 Modbus Plus local

1 USB local

1 Ethernet TCP/IP Hot Standby 140NOE77111 local

Checks: Process control; Hot standby

Memory description:

Expandable 7168 kB - program with PCMCIA card

Expandable 8 MB - file storage with PCMCIA card

Internal RAM 1024 kB - 512 kB for data

Switch Function: Key switch memory port on/off

Application structure: 1 cyclic/periodic master task

Execution time per instruction:

0.09...0.12 µs on word

0.105...0.15 µs Boolean

0.96...1.02 µs on fixed-point arithmetic

Execution time for 1 Kinstruction:

5.03 65 % Boolean and 35 % numerical

5.14 100 % Boolean

System overhead: 1.5 ms master task

Bus current requirement: 2500 mA

Maximum supply current:

90 A 140 °F (60 °C) lithium battery

60 µA lithium battery

[Us] rated supply voltage: 3 V DC lithium battery

Battery Capacity: 1200 Ah

Battery life: 10 year(s)

Display type: LCD 2 lines of 16 characters

Local signalling:

for Ethernet activity (COM) 1 LED (green)

for Ethernet collision (ERR) 1 LED (red)

Electrical connection:

1 female connector SUB-D 9 for connecting to the Modbus Plus network

1 female connector USB type B for connecting to PC

2 connectors RJ45 for connecting Modbus bus

Marking: CE

Environment

Product Certifications: TÜV Rheinland (SIL3); C-tick; CSA
