Schneider 140CPS52400 MODICON QUANTUM POWER SUPPLY - 125 V DC 100..150 V - REDUNDANT - 8 A
The Schneider Electric 140CPS52400 is a power supply module designed for various applications that require a reliable and redundant power source. Manufactured by Schneider Electric, a leading company in energy management and automation, this model offers a range of features and specifications that make it suitable for demanding industrial environments. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage.
Technical specifcations for 140CPS52400
Main
Range of Product: Modicon Quantum automation platform
Product or Component Type: Power supply module
Power supply type: Redundant
Complementary
Input voltage: 125 V 100...150 V) DC
Input current: 500 mA 125 V
Inrush current: 28 A 125 V
Maximum input power interruption: 1 ms
Associated fuse rating: 2 A, slow-blow
Output voltage: 5.1 V DC
Power supply output current: 8 A redundant
Output overvoltage protection: Internal
Output overload protection: Internal
Power dissipation: 6 + (1.5 x Iout) where Iout is in A
Local signalling: for power (PWR OK) 1 LED (green)
Marking: CE
Module format: Standard
Net Weight: 1.43 lb(US) (0.65 kg)
Environment
Standards: CSA C22.2 No 142; UL 508
Product Certifications: FM Class 1 Division 2; cUL
Resistance to electrostatic discharge: 4 kV contact IEC 801-2; 8 kV on air IEC 801-2
Resistance to electromagnetic fields: 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Ambient Air Temperature for Operation: 32…140 °F (0…60 °C)
Ambient Air Temperature for Storage: -40…185 °F (-40…85 °C)
Relative Humidity: 95 % without condensation
Operating altitude: <= 16404.2 ft (5000 m)
