Schneider 140CPS12420 MODICON QUANTUM POWER SUPPLY MODULE - 115 V/230 V AC - REDUNDANT
The Modicon 140CPS12420 is a power supply module manufactured by Schneider Electric for the Modicon Quantum automation platform. It is a 115 V/230 V AC – redundant module. It is a safety module made for use in a Quantum Safety PLC. It is certified for use in SIL 3 applications. These products are manufactured in France and are designed for Material handling, packaging, and textile machine usage.
Technical specifcations for 140CPS12420
Dimensions: 31.8 cm x 17.2 cm x 5.1 cm
Weight: 0.65 kg
Description: 140CPS12420 | Scheinder Electric | Power Supply Module
Main
Range of Product: Modicon Quantum automation platform
Product or Component Type: Power supply module
Power supply type: Redundant
Complementary
Input voltage: 115 V 93...138 V) AC 47…63 Hz; 230 V 170...276 V) AC
Input current: 1100 mA 115 V; 600 mA 230 V
Inrush current: 19 A 230 V; 38 A 115 V
Rated power in VA: 130 VA
Associated fuse rating: 2 A, slow-blow
Harmonic distortion: <= 10 % of fundamental rms value
Output voltage: 5.1 V DC
Power supply output current: 11 A 140 °F (60 °C) standalone; 10 A 140 °F (60 °C) redundant
Output overvoltage protection: Internal
Output overload protection: Internal
Power dissipation: 6 + (1.5 x Iout) where Iout is in A
Alarm output: 1 NC 6 A 220 V power supply fault
Local signalling: for power (PWR OK) 1 LED (green)
Marking: CE
Module format: Standard
Net Weight: 1.43 lb(US) (0.65 kg)
Environment
Standards: UL 508; CSA C22.2 No 142
Product Certifications: cUL
Resistance to electrostatic discharge: 4 kV contact IEC 801-2; 8 kV on air IEC 801-2
Resistance to electromagnetic fields: 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Ambient Air Temperature for Operation: 32…140 °F (0…60 °C)
Ambient Air Temperature for Storage: -40…185 °F (-40…85 °C)
Relative Humidity: 95 % without condensation
Operating altitude: <= 16404.2 ft (5000 m)
