Allen bradley 5069-OA16 Compact 5000 AC Output Module
The Allen-Bradley/Rockwell Automation 5069-L350ERM controller is a standard type of CompactLogix 5380 series controller. It features 5 MB of total user memory. The 5069-L350ERM standard controller can control 24 motion axes at a time. It can be used in an Ethernet network with up to 60 network nodes in it. The 5069-L350ERM standard controller has an operating temperature range from 0 to 60 degrees Celsius.
Technical specifications for 5069-OA16
| Manufacturer | Rockwell Automation |
| Module Type | AC Output module |
| Part Number/Catalog No. | 5069-OA16 |
| Brand | Allen-Bradley |
| Product Family: | Compact I/O modules |
| No. of channels | Sixteen (16) |
| Output Voltage: | 85-264VAC |
| Output Frequency: | 47-63 Hz |
| Output Current, channel: | 0.5 A |
| Output Current, module: | 4.0 A |
| MOD Power: | 100 mA @ 18…32V DC |
| SA Power: | 4 A @ 85…264V AC |
| Removable Terminal Block (RTB): | 5069-RTB18-SCREW; 5069-RTB18-SCREW |
| Wire size: | 0.5…1.5 mm2 (22…16 AWG) solid or stranded shielded copper wire rated at 105 °C (221 °F), or greater, 3.5 mm (0.14 in.) max diameter including insulation, single wire connection only. |
| Spring Type: | 0.5…1.5 mm2 (22…16 AWG) solid or stranded shielded copper wire rated at 105 °C (221 °F), or greater, 2.9 mm (0.11 in.) max diameter including insulation, single wire connection only. |
| Operating Temperature: | 0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F) |
| Enclosure: | None (Open type) |
| Series | Compact 5000 I/O |
| No. of Outputs | Sixteen (16) AC output channels |
| Output Voltage signal, nominal | 120 / 240VAC |
| Output current per module, max | 4:00 AM |
| Pilot Duty rating | 0.5 A pilot duty |
| No. of output groups | One (1) |
| Removable Terminal Block | 5069-RTB18-SPRING RTB; 5069-RTB18-SCREW RTB |
| Output states (Fault mode, fault state Program mode) | Hold Last State; On; Off (default) |
| Duration of fault mode per point | 1 s, 2 s, 5 s, 10 s, Forever (default) |
| Number of Inputs | N/A |
| Number of Outputs | 1 Group of 16 Channels |
| Voltage Category | 120/240 Volts AC |
| Input Voltage Range | N/A |
| Output Voltage Range | 85-264 Volts AC |
| Power Dissipation | 3.4 Watts |
| Enclosure Type | None (Open Style) |
| Dimensions | 5.4 x 0.87 x 4.2 in (138 x 22 x 105 mm) |
| Weight | 0.39 lbs (175 g) |
| Pulse Latching Supported | Yes |
| Pattern Matching Supported | Yes |
