Allen Bradley 2711P-T12C4A7 PowerFlex 700 Brand new

Allen Bradley  2711P-T12C4A7  PowerFlex

The Allen-Bradley 2711P-T12C4A7 is a Panelview Plus CE 1250 Operator Terminal. This operator terminal is powered by an external 85-264VAC supply voltage and has a 12.1-inch colored display with embedded RS232 and Ethernet communication ports.

Technical specifications for 2711P-T12C4A7

Display Type：Color active matrix, thin-film transistor (TFT) with liquid crystal display (LCD)

Display Size：12.1 inches

Brand：Allen-Bradley

Manufacturer:Rockwell Automation

Product Family:PanelView Plus CE Operator Terminals

Product Type:PanelView Plus 1250 Operator Terminals

Operator Input:Touch

Lifecycle status:Discontinued

Backlight:CCFL 50,000 hours life, min.

Display Area:246 x 184 mm (9.69 x 7.25 in)

Resolution:800 x 600

Toiuchscreen:1 million presses

Actuation force:10-110 g

Internal memory:256 MB Flash Memory / 256 MB Random Access Memory

Integrated ports:Ethernet, Data Highway Plus (DH+), Remote I/O (RIO), DH485, RS232, USB communication ports.

Input Voltage range:85-264VAC

Frequency:47-63 Hz

Part Number/Catalog No：.2711P-T12C4A7

Product Line：Panelview Plus 1250

Input Type：Touchscreen

Communication：Serial or Ethernet

Input Power：85-264 Volts AC

Memory：256 Megabytes

Shipping Dimensions：11.12 x 14.3 x 2.17 inches

Product Lifecycle Status*：Discontinued/Obsolete

Description

The PanelView Plus CE 1250 operator terminal with catalog number 2711P-T12C4A7 is a visualization component that is commonly referred to as Human Machine Interface (HMI). This HMI is primarily used to integrate data of one or more controllers and display these collected data to the HMI’s display screen for monitoring purposes. Another primary use of this operator terminal is to provide a user-friendly interface to control the connected processes or machines. Overall, this operator terminal centralizes monitoring and control point and provides a convenient operator workstation in the factory floor area.

Through the built-in Ethernet and RS232 communication interfaces, the 2711P-T12C4A7 connects to partner devices to send commands and receive data and information. For networked application and communication with one or more controllers simultaneously, the Ethernet communication port may be used while for peer-to-peer connection, use the RS232 communication interface. These communication interface operate independently from each other and allows operation one at a time or simultaneously. Additionally, the operator terminal may be operated using a USB compatible mouse or keyboard by attaching these to the available USB interface port.
