Allen Bradley 2711P-T10C4D7 PowerFlex
The 2711P-T10C4D7 operator interface terminal is a DC-powered operator interface terminal from the Allen-Bradley Panelview Plus 1000 series. It operates with an input voltage range from 18 to 32 Volts DC. The 2711P-T10C4D7 operator interface terminal is controlled by a 10-inch touchscreen that supports color graphics. It uses the Ethernet port for communication with other machines and for application transfers. The 2711P-T10C4D7 operator interface terminals users can replace the touchscreens backlight when necessary.
Technical specifications for 2711P-T10C4D7
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-T10C4D7
Product Line:Panelview Plus 1000
Display Size:10.4 in.
Display Color:Color
Input Type:Touchscreen
Communication:Ethernet and RS-232
Input Power:18-32 VDC
Memory:256 MB
Backlight:2711P-RL10C2
Communication Cable:1761-NET-ENI
Shipping Weight:9 lbs.
Shipping Dimensions:16 x 11 x 8 in
Series:Ser A, B, C, D, and F
UPC:10612598349279
Product Lifecycle Status*:Discontinued/Obsolete
Description:
The obsolete Allen Bradley Panelview Plus 1000 2711P-T10C4D7 is an operator terminal that allows the user to interface with their machine. This HMI has a 10.4 in. Color Display screen. The user is able to control the operator terminal using the Touchscreen to input information and data. This unit is powered using 18-32 VDC power. This Panelview Plus has the following internal memory: 256 MB. This unit has an internal backlight replacement part number of 2711P-RL10C2. The approximate shipping weight and dimensions are 9 lbs. and 16 x 11 x 8 in. The most common Series are: Ser A, B, C, D, and F. EtherNet/IP (Ethernet Industrial Protocol) is an open industrial network that supports real time I/O messaging, as well as message exchange. The Ethernet port connects to a controller on an EtherNet/IP network by using both the network and standard Ethernet connections. This port can work with application transfers and printing as well. The EtherNet/IP screen displays and allows the user to modify some of the EtherNet/IP communication settings for a PanelView terminal. If another port is required, the 2711P-RN20 Ethernet communication module is available for the 700 to 1500 Panelview Plus terminals. Each module has a specific and unique IP address. This port has an RJ45, 10/100Base-T connector for network communication and enables MDI/MDI-X connections. The parameters can be downloaded with the application.
