Allen Bradley 2711P-B12C4D8 PowerFlex 700 Brand new

Allen Bradley 2711P-B12C4D8  PowerFlex

The Allen-Bradley/Rockwell Automation 2711P-B12C4D8 terminal is a control terminal from the Allen-Bradley Panelview Plus 6 series. It can control a variety of machines and industrial control systems in a variety of applications. The 2711P-B12C4D8 control terminal supports a keypad and a touchscreen that control both the terminal itself and the machine that the terminal is connected to. The touchscreen is 12 inches wide with color graphics and the keypad includes programmable function keys. The 2711P-B12C4D8 control terminal operates at 18 to 32 Volts DC.

Technical specifications for 2711P-B12C4D8

Manufacturer:Rockwell Automation

Backlight:50,000 hr LED backlight life

Display Size:12.1 inches

Part Number/Catalog No.:2711P-B12C4D8

Brand:Allen-Bradley

Product Family:PanelView Plus 1250 Standard Terminals

Product Type:Operator Terminals

Operator Input:Keypad / Touch

Display Type:Color active matrix, thin-film transistor (TFT)

Lifecycle status:Active

Display Area:246 x 184 mm (9.7 x 7.2 in.)

Resolution:800 x 600, 18-bit color graphics

Keypad:1 million presses

Keypad function keys:F1 to F20, K1 to K20; 0…9, Special Characters, Backspace, Enter, Left and Right Tab, keys, Shift keys

Touchscreen:8-wire Analog Resistive Touchscreen

Operating force:10-110 g

Internal memory:512 MB RAM, 512 MB nonvolatile memory (approx. 79 MB free user memory)

Integrated ports:Ethernet, RS-232, 2 USB host

Input Voltage range:18-32VDC

Product Line:Panelview 6 Plus

Display Color:Color

Input Type:Keypad/Touchscreen

CommunicationEthernet and :RS-232

Input Power:18-32 VDC

Memory:512 MB RAM

Communication Cable:2711-NC14

Shipping Weight1:0 lbs.

Shipping Dimensions:20 x 14 x 8 in

Series:Series A and Series B

Description:

The current Allen Bradley Panelview 6 Plus 2711P-B12C4D8 is an HMI that allows the user to interact with their machine. This operator interface has a 12.1 in. Color Display. The user is able to control the operator interface by utilizing the Keypad/Touchscreen to input information and data. This unit is powered using 18-32 VDC power. This unit has 512 MB RAM memory. The approximate shipping weight and dimensions are 10 lbs. and 20 x 14 x 8 in. This HMI is built with EtherNet/IP (Ethernet Industrial Protocol) is an open industrial network that supports real time I/O messaging, as well as message exchange. The Ethernet port connects to a controller on an EtherNet/IP network by using both the network and standard Ethernet connections. This port can work with application transfers and printing as well. The EtherNet/IP screen displays and allows the user to modify some of the EtherNet/IP communication settings for a PanelView terminal. The 2711P-RN20 Ethernet communication module is available for the 700 to 1500 terminals if another Ethernet port is required. The module has its own unique IP address. This port has an RJ45, 10/100Base-T connector for network communication and supports MDI/MDI-X connections. The parameters are downloaded with the application.
