Allen Bradley 2711P-T10C15A6 PowerFlex
The 2711P-T10C15A6 operator interface terminal is an Allen-Bradley/Rockwell Automation interface terminal from the Panelview Plus 1000 terminal series. Its 10.4-inch screen is both a display screen and a touchscreen and it supports color graphics. The users can operate the 2711P-T10C15A6 operator interface terminals touchscreen with their bare hands, with gloved hands, or with plastic styluses that are not too sharp. This terminal operates with AC voltage and with the ControlNet communication network. The 2711P-T10C15A6 operator interface terminals screen is illuminated by a replaceable backlight.
Technical specifications for 2711P-T10C15A6
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2711P-T10C15A6
Product LinePanelview Plus 1000
Display Size10.4 in.
Display ColorColor
Input TypeTouchscreen
CommunicationControlNet
Input Power85-264 VAC
Memory128 MB
Backlight2711P-RL10C2
Communication Cable1747-KFC15A
Shipping Weight9 lbs.
Shipping Dimensions16 x 11 x 8 in
SeriesSer A, B, C, D, and F
Product Lifecycle Status*Discontinued/Obsolete
Description
The obsolete Allen Bradley Panelview Plus 1000 2711P-T10C15A6 is an operator terminal that allows the user to interface with their machine. This HMI has a 10.4 in. Color Display screen. The user is able to control the operator terminal using the Touchscreen to input information and data. This unit is powered using 85-264 VAC power. This Panelview Plus has the following internal memory: 128 MB. This unit has an internal backlight replacement part number of 2711P-RL10C2. The approximate shipping weight and dimensions are 9 lbs. and 16 x 11 x 8 in. The most common Series are: Ser A, B, C, D, and F. The ControlNet terminals are able to connect to single or multiple controllers on a unique ControlNet network. They support both scheduled and unscheduled access to controller data, as well as support for redundant cabling. The ControlNet terminals support symbolic CIP addressing when communicating with a ControlLogix system. Every terminal offers a Network Access port for local access to the ControlNet network.
