Allen Bradley 2711P-K6M1D PowerFlex
The Allen-Bradley/Rockwell Automation 2711P-K6M1D terminal is an operator interface terminal from the Panelview Plus 600 terminal series. Its voltage ratings include 18 to 30 Volts DC of input voltage and 24 Volts DC of nominal voltage. The 2711P-K6M1D operator interface terminal can only support grayscale graphics on its screen for displaying menus and application data. It comes with a keypad for data input and device control. The users of the 2711P-K6M1D operator interface terminal can save up to 10 frequently used functions at a time with the terminals 10 programmable function keys.
Technical specifications for 2711P-K6M1D
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-K6M1D
Series:PanelView Plus 600
Module Type:Operator Interface Terminal
Input Type:Keypad
Power Supply:24 Volts DC
Communication:RS-232, USB, Ethernet, RIO
Display:5.7-inch Monochrome
Product Lifecycle Status*:Discontinued/Obsolete
Description
The Allen-Bradley 2711P-K6M1D PanelView Plus 600 operator interface device provides easy machine control through its stainless-steel keypad with navigational, numerical, and functional (F1-F10) keys, with 340G of operating shock and 1 million presses in actuation. The 2711P-K6M1D displays the machine’s information graphically through the 5.7-inch monochrome passive matrix FSTN display with a display area of 4.37in x 3.3in and a display brightness of 300 cd/m2 Nits. It also provides a 320 x 240, 32-level grayscale display resolution and it is equipped with a cold-cathode fluorescent backlight with a standby time of 50,000 hours. It has an internal battery-backed clock with ±2 min per month accuracy and a maximum battery life of 5 years. The 2711P-K6M1D connects with external devices and a computer through its single USB 1.1 port, and it communicates using the base-configured serial RS-232 and 10/100 Mbps Ethernet Communication port and a Remote I/O communication module for extended Remote modular I/O connectivity.
