Allen Bradley 2711P-B4C20D8 PowerFlex
The 2711P-B4C20D8 terminal is an Allen-Bradley PanelView Plus 6 industrial terminal. The 2711P-B4C20D8 terminal includes a 3.5-inch display and it runs on DC power.
Technical specifications for 2711P-B4C20D8
Brand:Allen-Bradley / Rockwell Automation
Series:Panelview Plus 6
Part Number:2711P-B4C20D8
Product type:Industrial terminal
Display:3.5 inches
Input power:18 to 30 Volts DC
Touchscreen:Yes
Keypad:Yes
Dimensions:6 x 7.28 x 2.35 inches
Cutout size:4.86 x 6.15 inches
Description
The Allen-Bradley 2711P-B4C20D8 PanelView Plus 6 industrial terminal includes a 3.5-inch display screen and it runs on DC power. The operating temperature range for the terminal is from 0 to 55 degrees Celsius and the storage and transportation temperature range is from -25 to 70 degrees Celsius. The heat dissipation for the 2711P-B4C20D8 terminal is 85 BTU per hour and the recommended ambient non-condensing relative humidity range is 5 to 95%. The maximum operating altitude is 6561 feet. The enclosure of the 2711P-B4C20D8 terminal is rated for NEMA/UL type 12, 13, and 4X protection levels for indoor use only. The operating and non-operating shock ratings are 15 G at 11 milliseconds and 30 G at 11 milliseconds. The 2711P-B4C20D8 terminal is certified by the CE, RMS, and RoHS standards.
