Allen Bradley 2711P-B15C22D PowerFlex 700 Brand new

Allen Bradley  2711P-B15C22D   PowerFlex

The Allen-Bradley 2711P-B15C22D is a PanelView Plus 7 Performance operator terminal. This Human Machine Interface (HMI) device is powered by an external supply voltage of 18-32VDC. It has a 15-inch Color active matrix, thin-film transistor (TFT) LCD screen with embedded Touchscreen and keypad operator interfaces. It has a variety of communication ports such as, Two (2) Ethernet and Three (3) USB ports.

Technical specifications for 2711P-B15C22D

Brand：Allen-Bradley

Display Size：15 inches.

Part Number/Catalog No.：2711P-B15C22D

Manufacturer：Rockwell Automation / Allen-Bradley

Product Family:PanelView Plus 7 Performance terminals

Operator Input:Touch / Keypad

Display Type:Color active-matrix TFT

Display Area:304 x 228 mm (12.0 x 9.0 in.)

Resolution:1024 x 768 XGA, 18-bit color graphics

Touch:Analog resistive Actuation: 1 million presses; operating force: 100 g

System Memory:512 RAM, 512 MB nonvolatile memory (approx. 80 MB free user memory)

Communication ports:Two (2) Ethernet, Three (3) USB host

Input Voltage range:18-30 VDC

Power Consumption:50 W max (2.1 A at 24V DC)

Backlight:White light-emitting diode, solid state Life: 50,000 h min at 40 °C (104 °F) to half-brightness, backlight is not replaceable

Product Line：Panelview Plus 7

Input Type：Touchscreen/Keypad

Display Color：Color

Memory：512 Mb

Input Voltage：24 VDC

Backlight：LED

Weight：9.13 LBS

Description:

The 2711P-B15C22D is a visualization component that is manufactured by Allen-Bradley. PanelView Plus 7 Performance operator terminal. This operator terminal is an industrial device, typically called as Human Machine Interface (HMI) that enables control of process or machine to implement automation in the factory floor.

The 2711P-B15C22D9P is a DC powered device that operates at an input supply range of 18-32VDC with nominal supply of 24VDC. It has a maximum power consumption of 50 W or 2.1 A at 24V DC. It measures 322 x 484 x 69.6 mm 12.68 x 19.06 x 2.74 in and weight approximately 4.14 kg (9.13 lb).

When installing the device, appropriate enclosures are NEMA and UL Type 12, 13, 4X, also rated IP66 as Classified by UL. This device is flush mounted to the mentioned enclosures and must be operated at an operating temperature of 0…55 °C (32…131 °F). Install appropriate cooling devices to maintain the required operating temperature with reference to the device’ typical heat dissipation of 61 BTU.
