Allen Bradley 25A-D013N114 AC Drive
The Allen-Bradley/Rockwell Automation 25A-D013N114 drive is an AC-powered PowerFlex 523 adjustable frequency drive. It features a standard interface, a Size C frame, and an EMC filter. The 25A-D013N114 adjustable frequency drive operates at 380 to 480 Volts AC input voltage and at 0 to 460 Volts AC output voltage. Both voltage ratings are for 3-phase AC voltage. The 25A-D013N114 adjustable frequency drive can support maximum normal duty and heavy-duty
Product Details
BASE DRIVE INFORMATION
Bulletin Number: PowerFlex 525 AC Drive, with Embedded EtherNet/IP and Safety
Voltage Class: 380...480V AC, 3 Phase
Output Current: 13 Amps
Enclosure Type: IP20 NEMA / Open Type
Frame Size: Frame C
Interface Module: Standard
EMC Filtering Options: Filter
ACCESSORIES
Circuit Protection: No Circuit Protection
Technical specifications for 25A-D013N114
Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Part Number/Catalog No.: 25A-D013N114
Series: PowerFlex 523
Voltage: Three Phase, 480 VAC
Output Current: 13 Amperes
Enclosure Type: IP20 NEMA / Open Type
Interface Module: Standard
Frame Size: Frame C
EMC Filtering Option: Single
FAQ & Contact:
Q: Are you a trading company or a manufacturer?
A: We are a trading company.
Q: What is your lead time?
A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.
Q: Does your company provide samples? Is it free or do you charge extra?
A: It depends on the goods you need and the quantity you order.
Q: What are your terms of payment?
A: 100% T/T before shipping. If the quantity is large, we can negotiate.
