Siemens 6ES7392-1BM01-0AA0 Accessories

Siemens 6ES7392-1BM01-0AA0 SIMAT1C S7-300

SIMAT1C S7-300, Front connector for signal modules with spring-oaded contacts, 40-pole

Technical specifcations for 6ES7392-1BM01-0AA0

Product family:  Front connectors

Net Weight (kg): 0.095 Kg

Range: Simatic S7

Subrange: S7-300

Product phase: Active

Dimensions(cm): 2,50x2,50x 12,70

Ambient conditions

Ambient temperature during operation

● min: 0 °C

● max: 60 °C

Ambient temperature during storage/transportation

● min: -40 °C

● max: 70 °C

Connection method

Connection I/O signals

● Connection method: Spring terminals

● Number of lines per connection: 1; Or 2 cables up to 0.75 mm² (total) in a shared end sleeve

Conductor cross-section in mm²

— Connectable cable cross-sections for massive cables, min: 0.25 mm²

— Connectable cable cross-sections for massive cables, min: 0.75 mm²

— Connectable cable cross-sections for flexible cables without end sleeve, min: 0.25 mm²

— Connectable cable cross-sections for flexible cables without end sleeve, max: 0.75 mm²

— Connectable cable cross-sections for flexible cables with end sleeve, min: 0.25 mm²

— Connectable cable cross-sections for flexible cables with end sleeve, max: 0.75 mm²

Conductor cross-section acc. to AWG

— Connectable cable cross-sections for massive cables, min: 24

— Connectable cable cross-sections for massive cables, min: 19

— Connectable cable cross-sections for flexible cables without end sleeve, min: 24

— Connectable cable cross-sections for flexible cables without end sleeve, max: 19

— Connectable cable cross-sections for flexible cables with end sleeve, min: 24

— Connectable cable cross-sections for flexible cables with end sleeve, max: 19

Wire end processing

— Stripped length of cables, min: 6 mm

— Stripped length of cables, max: 6 mm

— End sleeve acc. to DIN 46228 without plastic sleeve: Design A, 5 mm to 7 mm long

— End sleeve acc. to DIN 46228 with plastic sleeve: Design E, up to 6 mm long

Dimensions

Width: 21.6 mm

Height: 126 mm

Depth: 40.9 mm

Weights

Weight, approx: 98 g
