Siemens 6ES7332-5HB01-0AB0 SIMATIC S7-300, Analog output SM 332
SIMATIC S7-300, Analog output SM 332, isolated, 2 AO, U/I; resolution 11/12 bits, 20-pole, Removing/inserting with active backplane bus possible
Technical specifcations for 6ES7332-5HB01-0AB0
Supply voltage
Load voltage L+
● Rated value (DC): 24 V
● Reverse polarity protection: Yes
Input current
from load voltage L+ (without load), max: 135 mA
from backplane bus 5 V DC, max: 60 mA
Power loss
Power loss, typ: 3 W
Analog outputs
Number of analog outputs: 2
Voltage output, short-circuit protection: Yes
Voltage output, short-circuit current, max: 25 mA
Current output, no-load voltage, max: 18 V
Output ranges, voltage
● 0 to 10 V: Yes
● 1 V to 5 V: Yes
● -10 V to +10 V: Yes
Output ranges, current
● 0 to 20 mA: Yes
● -20 mA to +20 mA: Yes
● 4 mA to 20 mA: Yes
Load impedance (in rated range of output)
● with voltage outputs, min: 1 kΩ
● with voltage outputs, capacitive load, max: 1 µF
● with current outputs, max: 500 Ω
● with current outputs, inductive load, max: 10 mH
Cable length
● shielded, max: 200 m
Analog value generation for the outputs
Integration and conversion time/resolution per channel
● Resolution with overrange (bit including sign), max: 12 bit; ±10 V, ±20 mA, 4 mA to 20 mA, 1 V to 5 V: 11 bit + sign; 0 V to 10 V, 0 mA to 20 mA: 12 bit
● Conversion time (per channel): 0.8 ms
Settling time
● for resistive load: 0.2 ms
● for capacitive load: 3.3 ms
● for inductive load: 0.5 ms; 0.5 ms (1 mH); 3.3 ms (10 mH)
Errors/accuracies
Operational error limit in overall temperature range
● Voltage, relative to output range, (+/-): 0.5 %
● Current, relative to output range, (+/-): 0.6 %
Basic error limit (operational limit at 25 °C)
● Voltage, relative to output range, (+/-): 0.4 %
● Current, relative to output range, (+/-): 0.5 %
Interrupts/diagnostics/status information
Diagnostics function: Yes; Parameterizable
Alarms
● Diagnostic alarm: Yes; Parameterizable
Diagnoses
● Diagnostic information readable: Yes
Diagnostics indication LED
● Group error SF (red): Yes
Potential separation
Potential separation analog outputs
● between the channels: No
