Siemens 6AV6648-0CE11-3AX0 Basic panels

Siemens 6AV6648-0CE11-3AX0 SIMATIC HMI SMART 1000 IE V3

SIMATIC HMI SMART 1000 IE V3, SMART Panel, Touch operation, 10" widescreen TFT display, 65536 colors, RS422/485 interface, Ethernet (RJ45) interface, host USB type A, RTC support, with CE certificate, configurable from WinCC flexible SMART; contains opensource software, which is provided free of charge see enclosed CD

Technical specifcations for 6AV6648-0CE11-3AX0

Display

Design of display: TFT

Screen diagonal:10.1 in

Display width: 222.7 mm

Display height: 125.3 mm

Resolution (pixels)

● Horizontal image resolution: 1024 pixel

● Vertical image resolution: 600 pixel

Backlighting

● MTBF backlighting (at 25 °C):15 000 h

● Backlight dimmable: No

Control elements

Keyboard fonts

● Function keys

— Number of function keys: 0

— Number of function keys with LEDs: 0

● Keys with LED: No

● System keys: No

● Numeric keyboard: Yes; Onscreen keyboard

● alphanumeric keyboard: Yes; Onscreen keyboard

Touch operation

● Design as touch screen: Yes

Supply voltage

Type of supply voltage: DC

Rated value (DC): 24 V

permissible range, lower limit (DC): 19.2 V

permissible range, upper limit (DC): 28.8 V

Input current

Current consumption (rated value): 230 mA

Current consumption, max: 370 mA

Starting current inrush I²t: 0.1 A²·s

Processor

Processor type: ARM, 600 MHz

Memory

Flash: Yes

RAM: Yes

Ambient conditions

Ambient temperature during operation

● Operation (vertical installation)

— For vertical installation, min: 0 °C

— For vertical installation, max: 50 °C

● Operation (max. tilt angle)

— At maximum tilt angle, min: 0 °C

— At maximum tilt angle, min: 40 °C

● Operation (vertical installation, portrait format)

— For vertical installation, min: 0 °C

— For vertical installation, max: 40 °C

● Operation (max. tilt angle, portrait format)

— At maximum tilt angle, min: 0 °C

— At maximum tilt angle, min: 35 °C

Ambient temperature during storage/transportation

● min: -20 °C

● max: 60 °C

Relative humidity

● Operation, max: 90 %; at <40 °C (no condensation)

Dimensions

Width of the housing front: 276 mm

Height of housing front: 218 mm

Mounting cutout, width: 259 mm

Mounting cutout, height: 201 mm

Overall depth: 39 mm

Weights

Weight without packaging: 1185 g
