Siemens 6AV6648-0CC11-3AX0 Basic panels

Siemens 6AV6648-0CC11-3AX0 SIMATIC HMI SMART 700 IE V3

SIMATIC HMI SMART 700 IE V3, SMART Panel, Touch operation, 7" widescreen TFT display, 65536 colors, RS422/485 interface, Ethernet (RJ45) interface, host USB type A, RTC support, with CE certificate, configurable from WinCC flexible SMART; contains opensource software, which is provided free of charge see enclosed C

Technical specifcations for 6AV6648-0CC11-3AX0

Display

Design of display: TFT

Screen diagonal: 7 in

Display width: 154.1 mm

Display height: 85.9 mm

Number of colors: 65536

Resolution (pixels)

● Horizontal image resolution: 800 pixel

● Vertical image resolution: 480 pixel

Backlighting

● MTBF backlighting (at 25 °C): 20 000 h

● Backlight dimmable: No

Control elements

Keyboard fonts

● Function keys

— Number of function keys: 0

● Keys with LED: No

● System keys: No

● Numeric keyboard: Yes; Onscreen keyboard

● alphanumeric keyboard: Yes; Onscreen keyboard

Touch operation

● Design as touch screen: Yes

Supply voltage

Type of supply voltage: DC

Rated value (DC): 24 V

permissible range, lower limit (DC): 19.2 V

permissible range, upper limit (DC): 28.8 V

Input current

Current consumption (rated value): 200 mA

Current consumption, max: 340 mA

Starting current inrush I²t: 0.1 A²·s

Processor

Processor type: ARM, 600 MHz

Memory

Flash: Yes

RAM: Yes

Memory available for user data: 8 Mbyte

Ambient conditions

Ambient temperature during operation

● Operation (vertical installation)

— For vertical installation, min: 0 °C

— For vertical installation, max: 50 °C

● Operation (max. tilt angle)

— At maximum tilt angle, min: 0 °C

— At maximum tilt angle, min: 40 °C

● Operation (vertical installation, portrait format)

— For vertical installation, min: 0 °C

— For vertical installation, max: 40 °C

● Operation (max. tilt angle, portrait format)

— At maximum tilt angle, min: 0 °C

— At maximum tilt angle, min: 35 °C

Ambient temperature during storage/transportation

● min: -20 °C

● max: 60 °C

Relative humidity

● Operation, max: 90 %; at <40 °C (no condensation)

Dimensions

Width of the housing front: 209 mm

Height of housing front: 155 mm

Mounting cutout, width: 192 mm

Mounting cutout, height: 138 mm

Overall depth: 39 mm

Weights

Weight without packaging: 765 g
