Schneider 140CPU11303C controller module
Concept processor 80186 Modicon Quantum - 1 Modbus plus, 2 Modbus RS232
Specifications
| Main | |
| Range of Product | Modicon Quantum automation platform |
| Product or Component Type | Processor |
| Software name | ProWORX 32 |
| Concept | |
| Processor name | 80186 |
| Mathematical coprocessor | Without |
| Complementary | |
| Clock frequency | 20 MHz |
| Memory description | Internal RAM 368 kB |
| Exact time for 1 Kinstruction | 0.3...1.4 ms LL984 |
| Watchdog timer | 250 ms |
| Clock drift | +/-8 s/day 32…140 °F (0…60 °C) |
| I/O words | 30 I/32 O distributed |
| 64 I/64 O max local | |
| 64 I/64 O remote | |
| I/O words/network | 500 I/500 O distributed |
| Drops/network | 63 distributed |
| Number of drops | 31 remote |
| Number of network | 2 remote |
| 3 distributed | |
| Battery type | Lithium 7 µA 210 µA |
| Battery Capacity | 1.2 Ah |
| Battery life | 10 year(s) |
| Number of port | 1 Modbus RS232 |
| 1 Modbus Plus | |
| Communication module processor capacity | 2 NOM, NOE, CR, NMS |
| Switch Function | Without key switch |
| Marking | CE |
| Bus current requirement | 790 mA |
| Module format | Standard |
| Net Weight | 0.7 lb(US) (0.3 kg) |
| Environment | |
| Product Certifications | FM Class 1 Division 2 |
| cUL | |
| Standards | UL 508 |
| CSA C22.2 No 142 | |
| Resistance to electrostatic discharge | 4 kV contact IEC 801-2 |
| 8 kV on air IEC 801-2 | |
| Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 |
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
| Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Relative Humidity | 95 % without condensation |
| Operating altitude | <= 16404.2 ft (5000 m) |
| Ordering and shipping details | |
| Category | 18150-QUANTUM CONTROLLERS,HSBY,COMM. |
| Discount Schedule | PC21 |
| GTIN | 3.59586E+12 |
| Returnability | No |
| Country of origin | FR |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.0 in (5 cm) |
| Package 1 Width | 6.5 in (16.5 cm) |
| Package 1 Length | 12.2 in (31 cm) |
| Package 1 Weight | 18.1 oz (514 g) |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 7 |
| Package 2 Height | 11.8 in (30 cm) |
| Package 2 Width | 11.8 in (30 cm) |
| Package 2 Length | 15.7 in (40 cm) |
| Package 2 Weight | 9.068 lb(US) (4.113 kg) |
| Unit Type of Package 3 | S04 |
| Number of Units in Package 3 | 21 |
| Package 3 Height | 11.8 in (30 cm) |
| Package 3 Width | 15.7 in (40 cm) |
| Package 3 Length | 23.6 in (60 cm) |
| Package 3 Weight | 26.074 lb(US) (11.827 kg) |
| Contractual warranty | |
| Warranty | 18 months |
