Schneider PLC ATV630C13N4 Variable speed drive
variable speed drive
This Altivar Process ATV630 variable speed drive can feed 3-phase synchronous and asynchronous power motors. It features 3 built-in RJ45 communication ports as standard, 1 Ethernet port, 2 serial ports. It works at a rated supply voltage from 380V to 480V AC. This drive provides up to 30% energy saving when on standby due to the innovative ‘‘Stop and Go’’operation without additional costs. It is suitable for motors with power rating up to 55kW / 75hp for applications requiring slight overload (up to 120%). It is suitable for motors with power rating up to 45kW / 60hp for applications requiring significant overload (up to 150%). It weighs 56.5kg and its dimensions are, 290mm wide, 922mm high, 323mm deep. This drive is focused on fluids management processing and energy saving, it offers extensive flexibility in water and wastewater, mining, minerals and metals, oil and gas and food and beverage applications. Accesso
Product Destination and Protection
The ATV630C13N4 AC Drive is tailored for use with both asynchronous and synchronous motors, offering versatility and compatibility across various motor types. It boasts a high degree of protection, with an IP21 rating according to IEC 61800-5-1 and IEC 60529 standards, ensuring resilience against dust and moisture ingress. Additionally, the drive is certified as UL Type 1 and UL 508C, further bolstering its protection capabilities.
Specifications
Range of Product:Altivar Process ATV630
Product or Component Type:Variable speed drive
Product Specific Application:Process and utilities
Device short name:ATV630
ATV630:Standard version
product destination: Asynchronous motor Synchronous motors
EMC filter:Integrated 164.04 ft (50 m) IEC 61800-3 category C2 Integrated 492.1 ft (150 m) IEC 61800-3 category C3
IP degree of protection:IP21IEC 61800-5-1 IP21IEC 60529
[Us] rated supply voltage :380...480 V
Degree of protection : UL type 1 UL 508C
Type of cooling:Forced convection
Supply frequency:50...60 Hz - 5...5 %
[Us] rated supply voltage:380...480 V - 15...10 %
Motor power kW:11 kW normal duty) 7.5 kW heavy duty)
