Omron CP1H-XA40DR-A I/O Module
PLC, 100-240 VAC supply, 24 x 24 VDC inputs, 16 x relay outputs 2 A, 4 x analog inputs, 2 x analog outputs, 20K steps program + 32K words data memory
Specification
Supply voltage type: AC
Number of digital inputs: 24
Input type :PNP/NPN
Number of digital outputs: 16
Output type :Relay
Program capacity: 20 K steps
Data memory capacity :32 K words
Logic execution time: 0.10 µs
Communication port(s): USB
Number of Ethernet ports :0
Number of USB ports: 1
Number of RS-232 ports :0
Number of RS-485 ports: 0
Communication option(s) :CAN, CompoBus/S Master, CompoBus/S Slave, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, EtherNet/IP, Ethernet TCP/IP, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485
Number of analog inputs :4
Number of analog outputs :2
Number of encoder input channels :4
Max. encoder input frequency: 100 kHz
Max. number of PTP axes: 0
Max. pulse output frequency :0 kHz
Max. number of analogue I/O channels :62
Max. number of local I/O points :320
Max. number of expansion units :7
Built-in auxiliary 24 VDC output: 300 mA
Operating temperature range: 0-55 °C
Product Height (unpacked) :90 mm
Product Width (unpacked) :150 mm
Product Depth (unpacked) :85 mm
Product Weight (unpacked): 750 g
Product
Type:Description
Category :Industrial Automation and ControlsControllersProgrammable (PLC, PAC)
Manufacturer: Omron Automation and Safety
Series: CP1H
Packaging: Box
Part Status :Active
Number of Inputs and Type :24 - Digital (20), Analog/Digital (4)
Number of Outputs and Type: 16 - Analog (2), Relay (14)
Expandable:7 Modules Max
Voltage - Supply :100 ~ 240VAC
Display Type: LED - Red Characters
Number of Characters Per Row: 2
Communications: USB, Option Cards Available
Memory Size :32K Words
Mounting Type :Chassis Mount, DIN Rail
Features: Battery Backup
Operating Temperature: 0°C ~ 55°C
Software :CX-One
Approval Agency: CE, cULus, Lloyd, NK
Weight: 1.7 lbs (771.1 g)
Base Product Number :CP1H-XA
