New Yokogawa AAI543 Analog Input Module
The Yokogawa AAI543 is a robust 16-channel isolated current output module designed for industrial automation systems. It reliably provides a 4 to 20 mA output signal and supports HART communication for configuration and diagnostics. This module features a standard switch-over response in redundant configurations, ensuring continuous operation in critical environments.
Technical Specifications
Number of Output Channels: 16
Output Signal:4 to 20 mA
Withstanding Voltage:1500 VAC between output and system,
for 1 minute
Allowable Load Resistance:0 to 750Ω
Circuit-open Detection: Less than 0.65 mA
Accuracy:±48μA
Data Update Period:10ms
Drift due to Ambient Temperature Change:±16 μA/10°C
Maximum Current Consumption:230 mA (5 V DC), 540 mA (24 V DC)
Weight:Approx.0.4kg
External Communication:Pressure clamp terminal, MIL
connector cable, dedicated cable (KS1)
HART Communication:Available
Switch-over Response: Standard in redundant configuration
Suffix Codes:
H:With digital communication (HART protocol)
0: Standard switch-over response in redundant
configuration with no explosion protection
3: With ISA Standard G3 option and temperature (-20 to 70 °℃) option
