Product description
The GE Fanuc IC693MDL931 isolated relay output module does not come with the power supply that it needs to operate the field devices connected to it and it does not offer fuses for overcurrent protection. Thus, both the power supply and the fuses for the load circuits have to be provided by the end-users.
The GE Fanuc IC693MDL931 isolated relay output module is provided with 8 LED status indicators on the top that correspond to each of the outputs and that will turn on and off to let the users know if each output is open or closed.
Discrete applications such as controlling solenoid valves, motor starters, and alarm indicators are the most common loads connected to the GE Fanuc IC693MDL931 isolated relay output module. The IC693MDL931 output module can be installed in any I/O port of the GE Fanuc 90-30 PLC series devices.
The IC693MDL931 module is an isolated relay output PCB module that is designed and manufactured by GE Fanuc as an accessory for the Series 90-30 GE PLCs or programmable logic controllers. It is suitable for use with a 24 Volts DC power supply or with a 120 to 240 Volts AC utility power supply at 50 to 60 Hertz.
The GE Fanuc IC693MDL931 isolated relay output module provides 8 isolated outputs, and 4 of them are normally closed while the other 4 are double throw outputs, meaning that they have both a normally closed and a normally open contact. The rated current for each output is of 8 Amps, and each relay output is isolated from the rest, with an individual common power terminal for every one of them.
Packing & Delivery
1)100% brand New and Original Factory Seal!
2)Warranty: 1 year
3)Package: Original packing with cartons.
4)Delivery time: Shipped in 3-7 days after payment
5) All the goods will be tested before shipment.
Our Services
1 All our products are new and original, and of good quality.
2 Our prices are very competitive.
3 We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.
4 All inquiries will be valued and will reply in 24 hours.
5 Fast shipping, and good after-sale service
Other series: IC200/IC693/IC694/IC695/IC697/IC698/ IS200/IS215/Relay module
