Product description
A Series 90-30 PLC system may be installed with up to Eight (8) Genius Bus Controllers or enhanced Genius Communications Modules. The achieve this configuration, the required firmware of the Series 90-30 PLC is Firmware 5.0 or later.
The IC693BEM331 is equipped with a variety of Status LEDs installed on the module’s front panel. These LEDs include OK and COM LED. The normal operation of the OK LED is steady on-state. This LED remains ON after power-up diagnostics are completed. The COM LED is steadily ON when the bus controller module is actively communicating and blinks for intermittent bus connection and error.
Compatible Series 90-30 PLC for use with the IC693BEM331 Bus Controller are IC693CPU311K, 321K, 331L or later and any version of the IC693CPU313, 323, 340, 341, 350, 351, 352, 360, 363, and 364. Required firmware for use is version 5.0 or later.
The GE Fanuc IC693BEM331 Bus Controller is able to handle a maximum of 128 bytes of incoming and outgoing data from the field devices on the Bus. The configuration of the GE Fanuc IC693BEM331 Bus Controller is done through an additional proprietary GE Fanuc handheld monitor. Some of the I/O device types that can send and receive data to a Series 90-30 PLC that is using the GE Fanuc IC693BEM331 Bus Controller as a communication interface include discrete I/O devices such as solenoid valves, motor starters, and limit switches or analog I/O devices such as pressure transmitters and temperature sensors. The manufacturer recommends mounting the GE Fanuc IC693BEM331 Bus Controller inside a protective enclosure in order to avoid direct contact with water, excess humidity, and extreme high and low extremes of temperatures. Any work requiring maintenance on the circuitry should be carried out only by qualified personnel, because the mishandling of the equipment or the incorrect connection of any its wiring can produce application process malfunctions, property damage, or serious injury.
Packing & Delivery
1)100% brand New and Original Factory Seal!
2)Warranty: 1 year
3)Package: Original packing with cartons.
4)Delivery time: Shipped in 3-7 days after payment
5) All the goods will be tested before shipment.
Our Services
1 All our products are new and original, and of good quality.
2 Our prices are very competitive.
3 We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.
4 All inquiries will be valued and will reply in 24 hours.
5 Fast shipping, and good after-sale service
