Allen-Bradley1769-OF2 Compact I/O analog output module

Allen-Bradley1769-OF2 Compact I/O analog output module

Description For 1769-OF2

 The Allen-Bradley 1769-OF2 is a Compact I/O analog output module with Two (2) single-ended output channels. This module is designed to deliver analog voltage signals such as ± 10VDC, 0 to 10VDC, 0 to 5VDC, 1 to 5VDC and analog Current signals such as 0-20 mA and 4-20 mA. This module is compatible for use with MicroLogix 1500 and CompactLogix controllers.

The 1769-OF2 output may be linked to Proprotional + Integral + Derivative (PID) controller, used for implementing manual and automatic control of analog control loops. If used with CompactLogix version 20.

The 1769-OF2 has a current load of 10 mA and a restive load on-current output of 0 to 500 ? (inclusive of wire resistance). It has a load-on voltage output range greater 1 k ? at 10 Volts DC and an inductive load per current output of 0.1 mH. The 1769-OF2 has a capacitive load per output voltage of 1 µF. It requires no field calibration and an accuracy margin of ±0.5% (Voltage full range at 25 degrees Celsius or 77 degrees Fahrenheit), and a ±0.35% (Current full range at 25 degrees Celsius (77 degrees Fahrenheit)). The 1769-OF2 compact voltage/current output module has a module error boundary around 0.8%, and an accuracy drift of ±0.0086% per degree Celsius. The output module also has a repeatability and nonlinearity margin of ±0.05%, and an output impedance of 15 ? .

The 1769-OF2 has a ±0.05% offset error margin and a 10ms time to detect an open wire condition. It equipped with short-circuit (21 mA maximum) and over-voltage protection. It has a copper wire with a 22 by 14 AWG solid size and single slot width. The 1769-OF2 has a weight of 0.65 pounds and dimensions of 4.65 by 1.38 by 3.43 inches.

Product specification

Model Number:1769-OF2

Product name:1769-OF2

Payment :Paypal\TT\Western Union\ Trade Assurance

MOQ :1PCS

Package :Carton Package

Shipping By DHL\UPS\Fedex\EMS\TNT\Aramex

Service :24 Hours Online Service

Lead time :5-7 Days

Condition :100% Original

Original factory:Allen-Bradley1769-OF2 In stock best price
