Allen bradley 5069-OB16F Compact 5000 Fast DC Output Module
The Allen-Bradley 5069-OB16F is a Compact 5000 Fast switching Discrete output module. This module features Sixteen (16) single group sourcing output channels that operates at voltage range of 10-32VDC. It provides output current of 0.5 A resistive per channel @ 10…32V DC and 8 A resistive per module @ 10…32V DC, max. This module features reduced output delay of 10 µs, ±1 µs @ 25 °C (77 °F) @ 0.5 A for faster response. It is capable of implementing scheduled outputs at resolution of 1 ns and accuracy of ±10 µs . This module may be used as Local I/O or distributed I/O component. It uses 5069-RTB18-SPRING RTB and 5069-RTB18-SCREW RTB.
Technical specifications for 5069-OB16F
Module Type | Fast switching DC Output module |
Part Number/Catalog No. | 5069-OB16F |
Brand | Allen-Bradley |
Manufacturer | Rockwell Automation |
Series | Compact 5000 I/O |
No. of Outputs | Sixteen (16) sourcing output channels |
Output Voltage signal, nominal | 24VDC |
Output Voltage Signal range | 10-32VDC |
Output current rating | 0.5 A resistive per channel @ 10…32V DC 8 A resistive per module @ 10…32V DC, max |
Surge Current per point | 1 A max for 10 ms per point, repeatable every 2 s |
Output delay time | ? 10 µs, ±10 µs @ 25 °C (77 °F) @ 0.5 A |
Pulse width, min | 20 µs @ 0.5 A @ 25 °C (77 °F) |
No. of output groups | One (1) |
Removable Terminal Block | 5069-RTB18-SPRING RTB; 5069-RTB18-SCREW RTB |
Output states (Fault mode, fault state Program mode) | Hold Last State; On; Off (default) |
Duration of fault mode per point | 1 s, 2 s, 5 s, 10 s, Forever (default) |
Number of Inputs | N/A |
Number of Outputs | 1 Group of 16 Channels (Sourcing) |
Voltage Category | 12/24 Volts DC Source |
Input Voltage Range | N/A |
Output Voltage Range | 10-32 Volts DC |
Power Dissipation | 3.25 Watts |
Enclosure Type | None (Open Style) |
Dimensions | 5.43 x 0.87 x 4.15 in (138 x 22 x 105 mm) |
Weight | 0.39 lbs (175 g) |
CIP Sync Supported | Yes |
Pattern Matching Supported | Yes |
