Allen Bradley 2711P-T12C15D2 PowerFlex
The 2711P-T12C15D2 operator interface terminal is an Allen-Bradley/Rockwell Automation Panelview Plus 1250 series operator interface terminal. It is controlled by a touchscreen and it operates with DC voltage. The 2711P-T12C15D2 operator interface terminals touchscreen measures 12.1 inches in diameter and it supports color graphics for displaying data and menus and for monitoring applications in progress. The input voltage rating for this terminal is from 18 to 32 Volts DC. The 2711P-T12C15D2 operator interface terminals touchscreen has an actuation rating of about 1 million presses.
Technical specifications for 2711P-T12C15D2
Manufacturer:Rockwell Automation
Display Type:Color active-matrix TFT
Display Size:12.1 inches
Part Number/Catalog No.:2711P-T12C15D2
Brand:Allen-Bradley
Product Family:PanelView Plus Compact Terminals
Product Type:Operator Terminals
Operator Input:Touch
Backlight:CCFL, 50,000 hours min at 25 ° C (77 °F),
Display Area:246 x 184 mm (9.7 x 7.2 in.)
Resolution:800 x 600
Input lifespan:1 million actuations
CompactFlash Memory, Max.512MB Flash Memory
Logic Module:128 MB
Integrated ports:ControlNet, Ethernet, RS-232, 1 USB host
Input Voltage range:18-32VDC
Product Line:Panelview Plus 1250
Input Type:Touchscreen
Communication:ControlNet
Input Power:18-32 Volts DC
Memory:128 Megabytes
Shipping Dimensions:11.12 x 14.3 x 2.17 inches
Product Lifecycle Status*:Discontinued/Obsolete
Description
The Allen-Bradley 2711P-T12C15D2 PanelView Plus 1250 12.1 Inches Standard Terminal is an interface device in the Allen-Bradley PanelView Plus Series of HMI, which provides an effective interface to machines for visualization, control, and maintenance. It has a compact design, with modularly-built components, and it has an integral/base configured unit, which allows for easy setup and saves installation time. The 2711P-T12C15D2 provides visualization as well as input through its 12.1-inch color active matrix, TFT LCD with an analog touchscreen, and a display Luminance of 300cd/m2 (Nits). It has a display area of 246mm x 184mm (9.7in x 7.2in), with a native resolution of 800 x 600 pixel, and it has a field replaceable backlight with about 50,000 hours of standby time. It has a compact memory card for slot for memory expansion of up to 512MB, and it comes with 1 RS-232 Serial Communication Port (for file transfer, printing, and logic controller communications), 2 USB Ports (for attaching mouse, keypad, and printer), 1 base configured 10/100 Base T Ethernet Port, and it supports a ControlNet Communication module. The 2711P-T12C15D2 is DC powered, and its input voltage range is 18 to 32V DC, with a maximum power consumption of 70W at 24V DC nominal, and its maximum heat dissipation is 240 BTU/hr. It has an operational temperature range of 32 to 131 °F, with a storage range of -13 to 158 ° F at 5 to 95% non-condensing relative humidity, and it IS designed to be resistant to a 15G operating shock, and a 2G peak vibration at 57 to 500Hz. The 2711P-T12C15D2 comes in a NEMA Type 12, 13, and 4X rated indoor enclosure, and it is cUL-us, CE, and C-TICK certified. It weighs approximately 3.2kg (7.1lb), and it has total shipping dimensions of 282mm x 363mm x 55mm (11.12in x 14.30in x 2.18in).
