Allen Bradley 2711P-T10C4B1 PowerFlex
The Allen-Bradley 2711P-T10C4B1 is a Panelview Plus 1000 Operator Terminal. This operator terminal is powered by an external 18-32VDC supply voltage and has a 10.4-inch colored display with embedded RS232 and Ethernet communication ports. This operator terminal has a Touchscreen input interface.
Technical specifications for 2711P-T10C4B1
Display Size:10.4 in
Backlight:CCFL 50,000 hours life, min.
Brand:Allen-Bradley
Manufacturer:Rockwell Automation
Product Family:PanelView Plus Operator Terminals
Product Type:PanelView Plus 1000 Operator Terminals
Operator Input:Touch
Display Type:Color active matrix, thin-film transistor (TFT) with liquid crystal display (LCD)
Lifecycle status:Discontinued
Display Area:211 x 158 mm (8.3 x 6.2 in.)
Resolution:640 x 480
Toiuchscreen:1 million presses
Actuation force:10-110 g
Internal memory:64MB Flash Memory / 64MB Random Access Memory
Integrated ports:Ethernet, Data Highway Plus (DH+), Remote I/O (RIO), DH485, RS232, USB communication ports.
Input Voltage range:18-32VDC
Part Number/Catalog No.:2711P-T10C4B1
Product Line:Panelview Plus 1000
Display Color:Color
Input Type:Touchscreen
Communication:Ethernet and RS-232
Input Power:85-264 VAC and 18-32 VDC
Memory:64 MB
Communication Cable:1761-NET-ENI
Shipping Weight:9 lbs.
Shipping Dimensions:16 x 11 x 8 in
Series:Ser A, B, C, D, and F
Product Lifecycle Status*:Discontinued/Obsolete
Description:
The obsolete Allen Bradley Panelview Plus 1000 2711P-T10C4B1 is an operator terminal that allows the user to interface with their machine. This HMI has a 10.4 in. screen. It has One (1) Ethernet and RS-232 communication port.
The user is able to control the operator terminal using the Touchscreen to input information and data. This unit is powered using 18-32 VDC power. This Panelview Plus has the following internal memory: 64 MB. This unit has an internal backlight replacement part number of 2711P-RL10C2. The approximate shipping weight and dimensions are 9 lbs. and 16 x 11 x 8 in.
