Allen Bradley 2711P-K6M5D PowerFlex
The 2711P-K6M5D terminal is an Allen-Bradley/Rockwell Automation Panelview Plus 600 series operator interface terminal. It is one of the simpler Panelview Plus 600 series terminals with a small 6-inch display screen that can only support grayscale graphics. The 2711P-K6M5D operator interface terminal uses a keypad for data input and control. It is DC-powered and it operates with a 24 Volts DC rated power supply. The 2711P-K6M5D operator interface terminal has 10 function keys that the users can program to save specific application functions
Technical specifications for 2711P-K6M5D
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-K6M5D
Series:PanelView Plus 600
Module Type:Operator Interface Terminal
Input Type:Keypad
Power Supply:24 Volts DC
Communication:RS-232, USB ports
Display:5.7-inch Monochrome
Product Lifecycle Status*:Discontinued/Obsolete
Description
The Allen-Bradley 2711P-K6M5D is a PanelView Plus 600 terminal with a monochrome display and a keypad input. The screen is a grayscale passive matrix FSTN screen with a display area of 4.37 x 3.30 inches. Its keypad features a stainless steel domed membrane and consists of numeric keys including navigation, backspace, and enter keys, tab and shift keys, and 10 configurable function keys. The keypad will respond to bare fingers or gloved fingers.
It has an RS-232 communication port available, as well as 1 USB port. This terminal also comes with a 64 MB non-volatile flash memory and a 64 MB RAM. This memory is not expandable and 20 MB is allotted for application storage. Enclosure ratings for the 2711P**-**K6M5D are NEMA Type 12, 13, 4X, IP54, and IP65. The terminal measures 6.58 x 10.47 x 3.86 inches and weighs 2.05 pounds.
FAQ & Contact:
Q: Are you a trading company or a manufacturer?
A: We are a trading company.
Q: What is your lead time?
A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.
Q: Does your company provide samples? Is it free or do you charge extra?
A: It depends on the goods you need and the quantity you order.
Q: What are your terms of payment?
A: 100% T/T before shipping. If the quantity is large, we can negotiate.
