Allen Bradley 2711P-K15C4D1 PowerFlex
The 2711P-K15C4D1 is a Human Machine Interface (HMI) device from Allen-Bradley’s PanelView Plus Product category. This operator terminal is part of the PanelView Plus 1500 which has a supply voltage range of 18-32 VDC. This terminal is equipped with a colored display 15-inch screen with resolution of 1024 x 768 pixels. It is equipped with keypad operator interface and communicates with partner automation devices through the embedded Ethernet and RS232 communication interfaces. It is also provided with USB interfaces that allows insertion peripheral devices.
Technical specifications for 2711P-K15C4D1
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:2711P-K15C4D1
Manufacturer::Rockwell Automation
Series:Panelview Plus 1500
Brand:Allen-Bradley
Input Method:Keypad Input
Product Family:PanelView Plus
Communicaion Ports:Standard Communication Ethernet, USB, RS-232
Product Type:PanelView Plus 1500
Power:24 VDC Input
Part Number:2711P-K15C4D1
Display Type15 in. Color Display
Input interfaces:Keypad
Features:64 MB
Display Type:Color Active Matrix TFT display
Display Area:304 x 228 mm (12.0 x 9.0 in.)
Product Lifecycle Status*:Discontinued/Obsolete
Resolution:1024 x 768
Backlight:50,000 hrs
Input interface lifespan:1 million presses
Real-time clock:Battery-backed clock timestamps critical data
Battery:Replaceable with part number 2711P-RY2032
Communication interface:Ethernet; RS232; USB
Input Voltage range:18-32 VDC
Input frequency:N/A
Enclosure:NEMA Type 12/13, 4X (Indoor use only), IP54, IP65
Description:
The Allen-Bradley 2711P-K15C4D1 is a PanelView Plus operator terminal. It belongs to the sub-category, PanelView Plus 1500 operator terminals. This electronic device has the largest display screen size among the PanelView Plus terminals, featuring a 15-inch, colored display screen with resolution of 1024 x 768 pixels with display area of 304 x 228 mm (12.0 x 9.0 in.). It runs a custom designed application that represents the operation of the process or machine, allowing centralized monitoring and control from the factory floor. The 2711P-K15C4D1 allows operators and plant personnel to input commands and navigate through the designed visualization screen via the provided keypad input interface. This keypad assembly is composed of function keys, nagivation, confirmation and alpha-numeric buttons. Only the function keys are programmable, accepting local and global assignments which vary depending on the current loaded screen of the HMI. The 2711P-K15C4D1 is designed to communicate with automation devices which is especially made in compatibility Allen-Bradley PLC5 and SLC 500 controllers. It is also compatible with modern controllers such as the Logix platform. This operator terminal is equipped with One (1) Ethernet communication interface that supports transmission rate of 10/100 mbps in linear topology. Redundancy may be accomplished with the use of external ethernet switch such as Allen-Bradley’s ETAP. For an alternative method of entering commands, the 2711P-K15C4D1 may be attached with a USB compliant mouse and keyboard via the on-board USB ports of this operator terminal. Removable storage such as a flash drive may also be inserted as additional means of data backup.
