Allen Bradley 2711P-B12C6A2 PowerFlex
The Allen-Bradley 2711P-B12C6A2 is a Panelview Plus 1250 Operator Terminal. This operator terminal is powered by an external 85-264VAC supply voltage and has a 12.1-inch colored display with embedded Ethernet, Data Highway Plus (DH+), Remote I/O (RIO), DH485, RS232, USB communication ports. This operator terminal has a keypad and touchscreen input interface.
Technical specifications for 2711P-B12C6A2
Display Type:Color active matrix, thin-film transistor (TFT) with liquid crystal display (LCD)
Display Size:12.1 inches
Brand:Allen-Bradley
Manufacturer:Rockwell Automation
Product Family:PanelView Plus Operator Terminals
Product Type:PanelView Plus 1250 Standard Terminals
Operator Input:Keypad / Touch
Lifecycle status:Discontinued
Backlight:CCFL 50,000 hours life, min
Display Area:246 x 184 mm (9.7 x 7.2 in.)
Resolution:800 x 600
Keypad:1 million presses
Keypad function keys:F1 to F20, K1 to K20; 0…9, Special Characters, Backspace, Enter, Left and Right Tab, keys, Shift keys
Touch:Analog Resistive
Internal memory:128MB Flash Memory / 128 MB Random Access Memory
Integrated ports:Ethernet, Data Highway Plus (DH+), Remote I/O (RIO), DH485, RS232, USB communication ports.
Input Voltage range:85…264V AC
Input Frequency:47…63 Hz
Part Number/Catalog No.:2711P-B12C6A2
Product Line:Panelview Plus 1250
Input Type:Touchscreen and Keypad
Communication:DH+/RIO/DH-485
Input Power:85-264 Volts AC
Memory:128 Megabytes
Shipping Dimensions:11.12 x 16.36 x 2.17 inches
Product Lifecycle Status:*Discontinued/Obsolete
Description
The 2711P-B12C6A2 is a PanelView Plus 1250 operator terminal from Allen-Bradley. This electronic device is a Human Machine Interface (HMI) that is used to integrate process or machine controller’s data and display the collected data in a manner that represents the control system or the critical monitoring and control points.
The 2711P-B12C6A2 features a 12.1-inch colored display screen that allows the implementation of color-coded graphics, providing a more informative process mimic. It has a resolution of 640 x 400 pixels and display area of 210 x 131 mm (8.27 x 5.17 in.). This operator terminal may be operated using the embedded touch screen that is designed up to 1 million presses with a recommended actuation force of 10-110g. The keypad assembly is composed of 40 fully programmable keys, numeric and navigation buttons.
The 2711P-B12C6A2 has a built-in memory with 128 MB Flash and Random-Access Memory (RAM). The flash memory is generally used to store application files, logs, trends and manuals. The Random Access Memory is utilized by the operator terminal during runtime to facilitate smooth and faster operation.
