Allen Bradley 25A-D037N114 AC Drive
The Allen-Bradley 25A-D037N114 PowerFlex 523 adjustable frequency AC drive. This drive features an input voltage range of 380-480VAC, 3-phase and delivers output voltage of 0-460VAC, 3-Phase, with rated Current of 37.0 A and Power of 18.5 kW (25 HP) for normal operation and 20 kW (15 HP) for heavy duty operation. It has an integral RS485 communication interface. It is capable of Volts / Hertz and Sensorles
Product Details
BASE DRIVE INFORMATION
Bulletin Number: PowerFlex 523 AC Drive
Voltage Class: 380...480V AC, 3 Phase
Output Current: 37 Amps
Enclosure Type: IP20 NEMA / Open Type
Frame Size: Frame E
Interface Module: Standard
EMC Filtering Options: Filter
ACCESSORIES
Circuit Protection: No Circuit Protection
Technical specifications for 25A-D037N114
Manufacturer Rockwell Automation
Part Number/Catalog No.: 25A-D037N114
Output Current: 37.0 A
Brand: Allen-Bradley
Product Family: PowerFlex 523 Adjustable Frequency AC Drive
Input Voltage: 380-480VAC
Input Phase: 3-Phase
Output Voltage: 0-460VAC
Output Power: 18.5 kW (25 HP) for normal operation; 20 kW (15 HP) for heavy duty operation
I/O: Discrete Inputs: Five (5) Inputs Discrete Outputs: One (1) Form C Contacts Analog Input: One (1) Analog Input Analog output: One (1) analog output
Installation: Panel Mount
Enclosure Rating: IP20 / NEMA UL Open Type
Frame: E
Control Method: Volts / Hertz Control; Sensorless Vector Control
Built-in communication port: RS485
Optional communication protocols: ProfiBus; Ethernet; DeviceNet;
EMC Filter: Integrated
Series: PowerFlex 523
Voltage: Three Phase, 480 VAC
Enclosure Type: IP20 NEMA / Open Type
Interface Module: Standard
Frame Size: Frame E
EMC Filtering Option: Single
UNSPSC: 39122001
