Allen Bradley 25A-D024N104 AC Drive
The 25A-D017N114 adjustable frequency drive is an Allen-Bradley/Rockwell Automation drive from the PowerFlex 523 drive series. Its output current rating is 17 Amps and its heavy-duty and normal duty output power ratings are both 10 Horsepower or 7.5 kilowatts. The 25A-D017N114 adjustable frequency drive comes in a Size C frame and it has an EMC filter. Its 3-phase output voltage range is 0 to 460 Volts AC and its 3-phase input voltage range is 380 to 480 Volts AC.
About
Technical specifications for 25A-D017N114Part Number 25A-D024N104 belonging to the Input / Output PowerFlex 523 AC Drives product line is a 3-phase Input / Output drive supplied by an input voltage of 380 to 480 volts AC. This AC drive is manufactured and designed by Allen-Bradley with a frame size D and enclosure protection rated as IP20 to protect it from environmental conditions. This drive has several Input / Output options available including both digital and analog options. The analog options include a single input powered through 0 to 10 volts or 4 to 20 milliamperes and a designated output option having functionality to compare speed with another drive. This drive has 5 digital inputs including a single stop function input and other 4 programmable function inputs. It also has a single digital relay output. This standard interface module can conserve energy via a common DC Bus.
Allen-Bradley’s 25A-D024N104 drive has the accessibility feature with multiple communication options that strengthen its ability to connect to modern control systems. This drive's design is easily programmable and can be configured with new settings due to the availability of changeable control and power modules. Therefore, to update the settings of the drive, you can simply connect the drive with a PC via a USB port. Other notable features of the 25A-D024N104 drive include a power rating of 11 kilowatts (15 horsepower), an output current of 24 amperes, an operational temperature of less than 45 °C, and controlling several motor controls as in sinusoidal pulse width modulation, volts per hertz, and sensorless vector control. This 25A-D024N104 can be connected with SCADA and HMI systems with ease.
Technical specifications for 25A-D024N104
Manufacturer Rockwell Automation
Brand: Allen-Bradley
Part Number/Catalog No.: 25A-D024N104
Series: PowerFlex 523
Voltage: Three Phase, 480 VAC
Output Current: 24 Amperes
Enclosure Type: IP20 NEMA / Open Type
Interface Module: Standard
Frame Size: Frame D
EMC Filtering Option: No Filtering
FAQ & Contact:
Q: Are you a trading company or a manufacturer?
A: We are a trading company.
Q: What is your lead time?
A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.
Q: Does your company provide samples? Is it free or do you charge extra?
A: It depends on the goods you need and the quantity you order.
Q: What are your terms of payment?
A: 100% T/T before shipping. If the quantity is large, we can negotiate.
