Allen Bradley 22C-D260A104 PowerFlex
The 22C-D260A104 is a PowerFlex 400 Adjustable Frequency AC Drive from Allen-Bradley. This drive is specifically designed for fan and pump application. It operates when supplied with voltage of 480VAC, 3-Phase. It delivers output power of 132.0 kW or 200.0 HP. The drive’s output Current is 260 Amperes with an IP30, NEMA UL Type 1 enclosure.
Specifications
Brand：Allen-Bradley
Part Number/Catalog No.：22C-D260A104
Input Voltage.：380-480VAC
Manufacturer.：Rockwell Automation / Allen-Bradley
Input Phase:3-Phase
Output Voltage:0-480VAC
Output Current:260 A
Output Power:132.0 kW or 200.0 HP
I/O:Discrete Inputs: Three (3) semi-programmable and Four (4) Fully programmable sink / source inputs Discrete Outputs: Two (2) Form C contacts and One (1) optocoupler output outputs Analog Input: One (1) Unipolar –10…10V or One (1) bipolar 0…10V or 4…20 mA. Analog Output: Two (2) 0-10VDC; 0-20mA
Installation:Panel Mount
Enclosure Rating:IP30 / NEMA UL Type 1
Built-in communication port:RS485
Control Method:Volts per Hertz (V/Hz), Sinusoidal PWM
Internal PID:Supported
EMC Filter:None
Human Interface Module:Integrated
Optional communication protocols:Dual Ethernet I/P; DeviceNet; ProfiBus DP
Product Line：Powerflex 400
Drive Type：Fan & Pump
Horsepower：200
Phase：Three-Phase
Enclosure：Panel Mount - IP30, NEMA/UL Type 10
Amperage：260 Amps
Description:
Part #：22C-D310A104
Category：Drives
Subcategory：Drive
Weight：255.00 lbs
Drive Type：PowerFlex 400,
Voltage Rating：480 VAC, 3 PHASE
Rating：310 AMP, 160 kW, 250 HP,
Enclosure：Panel Mount - IP30 NEMA Type 1,
HIM：FIXED KEYPAD
Emission Class：NOT FILTERED
Version：RS485
FAQ & Contact:
Q: Are you a trading company or a manufacturer?
A: We are a trading company.
Q: What is your lead time?
A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.
Q: Does your company provide samples? Is it free or do you charge extra?
A: It depends on the goods you need and the quantity you order.
Q: What are your terms of payment?
A: 100% T/T before shipping. If the quantity is large, we can negotiate.
